1797110000
- Mfr.Part #
- 1797110000
- Manufacturer
- Weidmuller
- Package / Case
- Datasheet
- Download
- Description
- TERM BLOCK HDR 5POS 90DEG 5MM
- Stock
- 8,581
- In Stock :
- 8,581
Request A Quote(RFQ)
- * Fullname:
- * Company:
- * E-Mail:
- Phone:
- Comment:
- * Quantity:
- Manufacturer :
- Weidmuller
- Product Category :
- Headers, Plugs and Sockets
- Housing Material :
- Liquid Crystal Polymer (LCP), Glass Filled
- Total Number of Contacts :
- 5
- Width :
- 12mm
- Factory Lead Time :
- 12 Weeks
- Current :
- 10A
- RoHS Status :
- RoHS Compliant
- Current Rating :
- 15A
- Height :
- 8.5mm
- MIL Conformance :
- No
- Packaging :
- Bulk
- Approval Agency :
- CSA, UR
- UL Flammability Code :
- 94V-0
- Mounting Type :
- Through Hole
- JESD-609 Code :
- e3
- Type :
- Header, Male Pins, Shrouded (4 Side)
- Pitch :
- 0.197 5.00mm
- Contact Mating Finish :
- Tin
- Option :
- GENERAL PURPOSE
- Mount :
- Through Hole
- Series :
- Omnimate SL
- Number of Levels :
- 1
- Termination Style :
- Solder
- Hole Diameter :
- 1.4 mm
- Color :
- Black
- Operating Temperature :
- -50°C~100°C
- Contact Tail Length :
- 0.059 1.50mm
- Length :
- 28.2mm
- Insulation Height :
- 0.335 8.51mm
- Material Flammability Rating :
- UL94 V-0
- Current - IEC :
- 27.5A
- Pbfree Code :
- yes
- Flammability Rating :
- UL94 V-0
- Lead Free :
- Lead Free
- Header Orientation :
- 90°, Right Angle
- Published :
- 2008
- Voltage - IEC :
- 400V
- Contact Material :
- COPPER ALLOY
- Number of Poles :
- 5
- IEC Conformance :
- No
- Voltage - Rated :
- 300V
- Filter Feature :
- No
- DIN Conformance :
- No
- Mixed Contacts :
- No
- Radiation Hardening :
- No
- Number of Rows :
- 1
- Voltage :
- 300V
- Current - UL :
- 18.5A
- Datasheets
- 1797110000

Bulk 0.197 5.00mm Black 1 Levels Through Hole Header, Male Pins, Shrouded (4 Side) Omnimate SL Liquid Crystal Polymer (LCP), Glass Filled Tin Copper Alloy
1797110000 Overview
Mounting type Through Hole is selected for the device.Packaged in a Bulk case.A member of the Omnimate SL Series.There's a Through Hole mount on the part.Device runs in -50°C~100°C operating temperature.Many Header, Male Pins, Shrouded (4 Side) products share the same benefits as this part.
1797110000 Features
Omnimate SL series
1797110000 Applications
There are a lot of Weidmüller
1797110000 Terminal Blocks applications.
