1606000000

Manufacturer :

Weidmuller

Product Category :

Headers, Plugs and Sockets

Width :

13.2mm

Lead Free :

Lead Free

Published :

2002

Voltage :

300V

Insulation Resistance :

1MOhm

Voltage - UL :

300V

Contact Mating Finish :

Tin

Current :

15A

MIL Conformance :

No

Height :

13mm

Radiation Hardening :

No

Operating Temperature :

-20°C~100°C

Number of Positions Per Level :

3

Flammability Rating :

UL94 V-0

Moisture Sensitivity Level (MSL) :

Not Applicable

UL Flammability Code :

94V-0

IEC Conformance :

No

RoHS Status :

RoHS Compliant

Series :

Omnimate SL

Termination Style :

Solder

Option :

GENERAL PURPOSE

Contact Material :

COPPER ALLOY

Mount :

Through Hole

Number of Levels :

1

Pbfree Code :

yes

Total Number of Contacts :

3

Mounting Type :

Through Hole

Material Flammability Rating :

UL94 V-0

Filter Feature :

No

Mixed Contacts :

No

Color :

Orange

Housing Material :

Polybutylene Terephthalate (PBT)

Insulation Height :

0.512 13.00mm

Factory Lead Time :

6 Weeks

Header Orientation :

135°

Pitch :

0.200 5.08mm

Contact Tail Length :

0.177 4.50mm

DIN Conformance :

No

Type :

Header, Male Pins, Shrouded (4 Side)

Packaging :

Bulk

Current - IEC :

12A

Voltage - IEC :

250V

Number of Rows :

1
