1544425-2
Or copy the link below:
- Mfr.Part #
- 1544425-2
- Manufacturer
- TE Connectivity AMP Connectors
- Package / Case
- Datasheet
- Download
- Description
- SIL CONTACT Y1 THROUGH HOLE
- Stock
- 35,512
- In Stock ：
- 35,512
Request A Quote(RFQ)
- * Fullname:
- * Company:
- * E-Mail:
- Phone:
- Comment:
- * Quantity:
- Manufacturer :
- TE Connectivity AMP Connectors
- Product Category :
- Leadframe
- Clip Type :
- Y1
- Orientation :
- Straight
- Frame Width :
- 0.713 18.10mm
- Length :
- 18.1mm
- Lead Length :
- 9.5mm
- Published :
- 2000
- Packaging :
- Tape and Reel (TR)
- Clip Style :
- SIL
- Pin Length :
- 0.374 9.50mm
- Contact Plating :
- Nickel, Tin
- Clip Length :
- 0.069 1.75mm
- Moisture Sensitivity Level (MSL) :
- 1 (Unlimited)
- Factory Lead Time :
- 25 Weeks
- Row Spacing :
- 2.54 mm
- Frame Thickness :
- 0.010 0.25mm
- MIL Conformance :
- No
- Contact Material :
- Phosphor Bronze
- Board Thickness :
- 0.025 0.64mm
- Assembly Item Name :
- Contact
- Contact Finish :
- Tin
- ELV :
- Compliant
- Pbfree Code :
- yes
- Contact Style :
- BELLOWED TYPE
- Radiation Hardening :
- No
- Lead Free :
- Lead Free
- RoHS Status :
- RoHS Compliant
- Termination :
- Through Hole
- Direction :
- Down
- REACH SVHC :
- Unknown
- Connector Support Type :
- CONNECTOR ACCESSORY
- Lifecycle Status :
- ACTIVE (Last Updated: 3 days ago)
- Pitch :
- 0.100 2.54mm
- IEC Conformance :
- No
- PCB Thickness :
- 630μm
- DIN Conformance :
- No
- Datasheets
- 1544425-2
