1479260000

Manufacturer :

Weidmuller

Product Category :

Headers, Plugs and Sockets

Number of Levels :

1

Operating Temperature :

-50°C~120°C

Option :

GENERAL PURPOSE

Type :

Plug Housing for Female Sockets

Total Number of Contacts :

10

Housing Material :

Polybutylene Terephthalate (PBT), Glass Filled

Mounting Type :

Free Hanging (In-Line)

MIL Conformance :

No

Packaging :

Bulk

Wire Gauge or Range - AWG :

14-26 AWG

Feature :

Retention Latches (Non-Wire Side)

Gender :

FEMALE

Moisture Sensitivity Level (MSL) :

1 (Unlimited)

Wire Gauge or Range - mm² :

0.22-2.5mm2

Mixed Contacts :

No

Pbfree Code :

yes

UL Flammability Code :

94V-0

Number of Positions :

10

Mating Information :

MULTIPLE MATING PARTS AVAILABLE

Plug Wire Entry :

180°

Color :

Orange

Current - UL :

10A

Pitch :

0.200 5.08mm

Factory Lead Time :

12 Weeks

Series :

Unimate BLA

Current - IEC :

20A

Voltage - IEC :

500V

Number of Rows :

2

Radiation Hardening :

No

IEC Conformance :

No

Voltage - UL :

300V

DIN Conformance :

No

Termination Style :

Crimp

RoHS Status :

RoHS Compliant

Material Flammability Rating :

UL94 V-0

Contact Material :

COPPER ALLOY

Insulation Height :

0.398 10.11mm

Filter Feature :

No
