1416010-1
Or copy the link below:
- Mfr.Part #
- 1416010-1
- Manufacturer
- TE Connectivity Potter & Brumfield Relays
- Package / Case
- Datasheet
- Download
- Description
- RELAY AUTOMOTIVE SPST 130A 12V
- Stock
- 1,560
- In Stock ：
- 1,560
Request A Quote(RFQ)
- * Fullname:
- * Company:
- * E-Mail:
- Phone:
- Comment:
- * Quantity:
- Manufacturer :
- TE Connectivity Potter & Brumfield Relays
- Product Category :
- Automotive Relays
- RoHS Status :
- RoHS Compliant
- Length :
- 74.168mm
- Depth :
- 40mm
- Contact Resistance :
- 50mOhm
- Coil Type :
- Non Latching
- Throw Configuration :
- SPST
- Lead Free :
- Not Applicable
- Weight :
- 220.162397g
- Switching Voltage :
- 12VDC - Nom
- Published :
- 2004
- Series :
- HCR 150
- Must Release Voltage :
- 1.2VDC
- Must Operate Voltage :
- 7.2VDC
- Number of Contacts :
- 1
- Termination Style :
- Screw Terminal
- Operate Time :
- 25ms
- Release Time :
- 8ms
- Mount :
- Screw
- Moisture Sensitivity Level (MSL) :
- Not Applicable
- Coil Voltage :
- 12VDC
- Lifecycle Status :
- ACTIVE (Last Updated: 2 days ago)
- Width :
- 40.005mm
- Packaging :
- Bulk
- Operating Temperature :
- -40°C~125°C
- Coil Voltage (DC) :
- 12V
- Factory Lead Time :
- 16 Weeks
- Height :
- 45mm
- Relay Type :
- Relay
- Current Rating :
- 130A
- Contact Form :
- SPST-NO (1 Form A)
- Contact Material :
- Silver Tin Oxide (AgSnO)
- Mounting Type :
- Chassis Mount
- Number of Pins :
- 4
- ELV :
- Compliant
- Coil Current :
- 324.3mA
- Max Current Rating :
- 300A
- Coil Power :
- 3.9W
- Coil Resistance :
- 37Ohm
- Datasheets
- 1416010-1
