09641007230

Manufacturer :

HARTING

Product Category :

D-Sub, D-Shaped Connector Adapters

IEC Conformance :

No

Moisture Sensitivity Level (MSL) :

1 (Unlimited)

Mount :

Free Hanging

MIL Conformance :

No

Depth :

28.55mm

Current Rating :

6.5A

Filter Feature :

yes

Orientation :

Straight

Connector Type B :

D-Sub, Standard

DIN Conformance :

No

Convert To (Adapter End) :

D-Sub, 9 Pin Female

Mounting Type :

Free Hanging (In-Line)

Length :

32.8mm

Connector Type A :

D-Sub, Standard

Housing Material :

Polychlorinated

Material Flammability Rating :

UL94 V-0

Option :

GENERAL PURPOSE

Capacitance :

1nF

Feature :

Filter

Mixed Contacts :

No

Gender Type B :

FEMALE

Working Voltage :

100V

Number of Pins :

1

RoHS Status :

ROHS3 Compliant

Number of Contacts :

9

Number of Rows :

2

Connector Style :

Connector Saver

Connector Type :

D-Sub

Operating Temperature :

-20°C~125°C

Gender Type A :

Male

Convert From (Adapter End) :

D-Sub, 9 Pin Male

REACH SVHC :

No SVHC

Max Supply Voltage :

100V

Gender :

Receptacle

Contact Finish - Mating :

NOT SPECIFIED

Contact Material :

NOT SPECIFIED

Housing Color :

Black

Includes :

3 pcs - 1 Connector, 2 Jack Screws

Straight Connection :

yes

Voltage - Rated DC :

100V

Empty Shell :

No
