VUI72-16NOXT

Manufacturer :

Littelfuse

Product Category :

Diodes - Bridge Rectifiers

Height :

17 mm

Manufacturer :

IXYS

Mounting Type :

Chassis Mount

Mount :

Chassis Mount

Qualification Status :

Not Qualified

Moisture Sensitivity Level (MSL) :

1 (Unlimited)

Configuration :

BRIDGE, 6 ELEMENTS WITH BUILT-IN IGBT AND THERMISTOR

Non-rep Pk Forward Current-Max :

530A

Operating Temperature :

-40°C~150°C TJ

Maximum Operating Temperature :

+125 C

Width :

31.6 mm

Diode Element Material :

SILICON

Surface Mount :

No

Length :

63 mm

Voltage - Peak Reverse (Max) :

1.6kV

Packaging :

Bulk

Terminal Position :

UPPER

Product Type :

Bridge Rectifiers

Current - Average Rectified (Io) :

75A

Current - Reverse Leakage @ Vr :

40μA @ 1600V

Rep Pk Reverse Voltage-Max :

1600 V

Terminal Form :

UNSPECIFIED

Number of Elements :

6

Product Category :

Bridge Rectifiers

JESD-30 Code :

R-XUFM-X12

Additional Feature :

HIGH RELIABILITY, UL RECOGNIZED

Vf - Forward Voltage :

1.38 V

Published :

2015

Minimum Operating Temperature :

- 40 C

RoHS Status :

ROHS3 Compliant

Case Connection :

Isolated

Brand :

IXYS

Base Product Number :

VUI72

Reach Compliance Code :

Compliant

Diode Type :

Three Phase

Voltage - Forward (Vf) (Max) @ If :

1.1V @ 25A

HTS Code :

8541.10.00.80

Type :

Three Phase Bridge

Number of Terminations :

12

Output Current-Max :

40A

Max Surge Current :

600 A

Termination Style :

Solder Pin

Number of Terminals :

12

Product Status :

Active

Package Shape :

RECTANGULAR

Package :

Bulk

Series :

--

Supplier Device Package :

V1A-PAK

Number of Phases :

3

Package / Case :

V1A-PAK

Mounting Style :

SMD/SMT
