VIPER15LN
Or copy the link below:
- Mfr.Part #
- VIPER15LN
- Manufacturer
- STMicroelectronics
- Package / Case
- 8-DIP (0.300, 7.62mm), 7 Leads
- Datasheet
- Download
- Description
- IC OFFLINE SWITCH FLYBACK 7DIP
- Stock
- 2,216
- In Stock ：
- 2,216
Request A Quote(RFQ)
- * Fullname:
- * Company:
- * E-Mail:
- Phone:
- Comment:
- * Quantity:
- Manufacturer :
- STMicroelectronics
- Product Category :
- AC DC Converters, Offline Switches
- Control Technique :
- PULSE WIDTH MODULATION
- Input Voltage (Max) :
- 23.5V
- Package / Case :
- 8-DIP (0.300, 7.62mm), 7 Leads
- JESD-609 Code :
- e3
- Terminal Finish :
- Matte Tin (Sn) - annealed
- Series :
- VIPer™ plus
- Length :
- 9.27mm
- Analog IC - Other Type :
- SWITCHING CONTROLLER
- Voltage - Supply (Vcc/Vdd) :
- 8.5V~23.5V
- Voltage - Start Up :
- 14V
- Pin Count :
- 7
- Operating Temperature :
- -40°C~150°C TJ
- Height :
- 3.3mm
- Topology :
- Flyback
- Terminal Pitch :
- 2.54mm
- Number of Terminations :
- 7
- Packaging :
- Tube
- Switcher Configuration :
- Single
- RoHS Status :
- ROHS3 Compliant
- ECCN Code :
- EAR99
- Input Voltage-Nom :
- 14V
- Base Part Number :
- VIPER15
- Output Isolation :
- Isolated
- Output Power :
- 12W
- Control Mode :
- CURRENT-MODE
- Internal Switch(s) :
- yes
- Mount :
- Through Hole
- Voltage - Breakdown :
- 800V
- Number of Outputs :
- 1
- Frequency - Switching :
- 136kHz
- Mounting Type :
- Through Hole
- Fault Protection :
- Current Limiting, Over Temperature, Over Voltage
- Power (Watts) :
- 10W
- Terminal Position :
- Dual
- Moisture Sensitivity Level (MSL) :
- 1 (Unlimited)
- Radiation Hardening :
- No
- Nominal Supply Current :
- 2.5mA
- Number of Functions :
- 1
- Number of Pins :
- 7
- Max Power Dissipation :
- 12W
- Operating Supply Current :
- 900μA
- Lead Free :
- Lead Free
- Input Voltage (Min) :
- 8.5V
- Datasheets
- VIPER15LN
AC DC Converters, Offline Switches STMicroelectronics VIPER15LN Overview
The VIPER15LN from STMicroelectronics is a high-performance integrated circuit specifically designed for offline switching applications. This IC is built to facilitate efficient energy conversion with minimal power loss, making it ideal for a broad range of power supply applications. The VIPER15LN is notable for its compact 7-DIP package, which integrates seamlessly into various electronic assemblies. Offering robust reliability and performance, this product by STMicroelectronics ensures that manufacturers can optimize their designs for both functionality and cost-effectiveness, making it a go-to choice for B2B customers looking to make bulk purchases for their sophisticated projects.
VIPER15LN Features
The VIPER15LN integrates multiple features that stand out in the realm of AC DC converters and offline switches. These include a built-in error amplifier, an oscillator with adjustable frequency, and thermal shutdown capability. Additionally, the device is designed with over-voltage, overload, and short-circuit protection, enhancing its durability and reliability in challenging environments.
VIPER15LN Applications
- Consumer Electronics: Used in power supplies for devices such as TVs and home audio systems, ensuring reliable operation and energy efficiency.
- Industrial Control Systems: Implements robust power solutions in automation machinery and control systems, providing stable performance in industrial settings.
- Smart Home Devices: Powers a variety of smart home technologies, contributing to overall system efficiency and dependable power management.
- Telecommunications Equipment: Essential in power systems for telecommunications infrastructure, where consistent and reliable power delivery is critical.
