V23047A1040A501
- Mfr.Part #
- V23047A1040A501
- Manufacturer
- TE Connectivity Potter & Brumfield Relays
- Package / Case
- Datasheet
- Download
- Description
- RELAY GEN PURPOSE DPDT 6A 40V
- Stock
- 21,296
- In Stock :
- 21,296
Request A Quote(RFQ)
- * Fullname:
- * Company:
- * E-Mail:
- Phone:
- Comment:
- * Quantity:
- Manufacturer :
- TE Connectivity Potter & Brumfield Relays
- Product Category :
- Power Relays, Over 2 Amps
- Comment :
- Well suited for emergency shut-off, machine control, elevator and escalator control, light barrier control
- Coil Resistance (Ω) :
- 2286
- Width Class (Mechanical) (mm) :
- 12 – 16
- Contact Limiting Continuous Current (A) :
- 6
- Product Height :
- 25.5?mm?[?1.004?in?]
- Environmental Ambient Temperature (Max) :
- 70?°C?[?158?°F?]
- Contact Number of Poles :
- 2
- Insulation Initial Dielectric Between Adjacent Contacts (Vrms) :
- 3000
- Terminal Type :
- PCB-THT
- Contact Material :
- AgNi
- Insulation Initial Dielectric Between Contacts & Coil (Vrms) :
- 4000
- Environmental Category of Protection :
- RTIII
- Relay Mounting Type :
- Printed Circuit Board
- Coil Voltage Rating (VDC) :
- 40
- Contact Special Features :
- Force Guided Contacts
- Packaging Method :
- Box and Tube, Tube
- Coil Power Rating (DC) (mW) :
- 700
- Contact Current Class (A) :
- 5 – 10
- Contact Limiting Making Current (A) :
- 6
- Published :
- 2015
- Length Class (Mechanical) (mm) :
- 25 – 30
- Product Length :
- 29?mm?[?1.142?in?]
- Insulation Clearance Between Contact & Coil :
- 8 mm [ .315 in ]
- Contact Limiting Short-Time Current (A) :
- 6
- Insulation Initial Dielectric Between Open Contacts (Vrms) :
- 1500
- Environmental Ambient Temperature Class (°C) :
- -25 – 70
- Contact Switching Load (Min) :
- 10mA @ 5V
- Insulation Initial Dielectric Between Coil & Contact Class (V) :
- 3500 – 4000
- Insulation Creepage Class (mm) :
- 5.5 – 8
- Product Width :
- 12.6?mm?[?.496?in?]
- Product Weight :
- 20?g?[?.706?oz?]
- Contact Arrangement :
- 2 Form C (CO)
- Contact Limiting Breaking Current (A) :
- 6
- Insulation Creepage Between Contact & Coil :
- 8 mm [ .315 in ]
- Power Relay Type :
- Force-Guided
- Height Class (Mechanical) (mm) :
- 25 – 30
- Coil Magnetic System :
- Monostable, DC
- RoHS Status :
- RoHS Compliant
- Contact Switching Voltage (Max) (VAC) :
- 400
- Coil Power Rating Class (mW) :
- 600 – 800
- Contact Current Rating (Max) (A) :
- 6
- Contact Voltage Rating (VAC) :
- 250
- Insulation Clearance Class (mm) :
- 5 – 8
- Datasheets
- V23047A1040A501
