TYN812RG

Manufacturer :

STMicroelectronics

Product Category :

Thyristors - SCRs

Terminal Position :

Single

Number of Terminations :

3

Weight :

6.000006g

Moisture Sensitivity Level (MSL) :

1 (Unlimited)

Number of Elements :

1

Hold Current :

30mA

Voltage - Off State :

800V

Forward Voltage :

1.6V

Width :

4.6mm

ECCN Code :

EAR99

Mount :

Through Hole

Mounting Type :

Through Hole

Radiation Hardening :

No

Factory Lead Time :

11 Weeks

Number of Pins :

3

Base Part Number :

TYN812

Current - Off State (Max) :

5μA

Terminal Finish :

Matte Tin (Sn) - annealed

Package / Case :

TO-220-3

Current - Non Rep. Surge 50, 60Hz (Itsm) :

140A 145A

Critical Rate of Rise of Off-State Voltage-Min :

200V/us

Trigger Device Type :

SCR

RoHS Status :

ROHS3 Compliant

Voltage - Rated DC :

800V

JEDEC-95 Code :

TO-220AB

Current - Gate Trigger (Igt) (Max) :

15mA

Operating Temperature :

-40°C~125°C

Packaging :

Tube

Current Rating :

8A

Voltage - Gate Trigger (Vgt) (Max) :

1.3V

Leakage Current (Max) :

2mA

Configuration :

Single

JESD-609 Code :

e3

Height :

9.15mm

Pin Count :

3

Length :

10.4mm

Max Repetitive Reverse Voltage (Vrrm) :

800V

Lead Free :

Lead Free

Non-Repetitive Pk On-state Cur :

146 A

RMS Current (Irms) :

12A

Voltage - On State (Vtm) (Max) :

1.6V

SCR Type :

Standard Recovery
