TS6B

Manufacturer :

Essentra Components

Product Category :

Max Repetitive Reverse Voltage (Vrrm) :

800 V

Number of Phases :

1

Lifecycle Status :

NRND (Last Updated: 2 years ago)

HTS Code :

8541.10.00.80

JESD-30 Code :

R-PSFM-T4

RoHS Status :

RoHS Compliant

Length :

25.3 mm

Forward Voltage-Max :

1V

Height :

15.3 mm

Additional Feature :

UL RECOGNIZED

Width :

3.7 mm

RoHS :

Non-Compliant

Max Forward Surge Current (Ifsm) :

150 A

Capacitance :

IR - 5uA

Forward Voltage :

1.1 V

Case Connection :

Isolated

Operating Temperature (Min) :

-55°C

Max Surge Current :

150 A

Surface Mount :

No

Reach Compliance Code :

Compliant

Max Junction Temperature (Tj) :

150 °C

Number of Terminals :

4

Terminal Position :

Single

Packaging :

TS4B

Max Reverse Leakage Current :

5 µA

Moisture Sensitivity Level (MSL) :

1 (Unlimited)

Output Current-Max :

6A

Diode Type :

BRIDGE RECTIFIER DIODE

Terminal Form :

THROUGH-HOLE

Configuration :

BRIDGE, 4 ELEMENTS

Breakdown Voltage-Min :

800V

Non-rep Pk Forward Current-Max :

150A

Voltage :

VRRM - 800V

Number of Elements :

4

Manufacturer :

TAIWAN SEMICONDUCTOR

Diode Element Material :

SILICON

Rep Pk Reverse Voltage-Max :

800V

Min Operating Temperature :

-55 °C

Max Operating Temperature :

150 °C

Manufacturer Lifecycle Status :

NRND (Last Updated: 2 years ago)

Operating Temperature (Max) :

150°C
