TS2N

Manufacturer :

NKK Switches

Product Category :

Panel Cutout Dimensions :

Circular - 10.30mm Dia

Number of Poles per Deck :

1

ECCN Code :

EAR99

Current Rating (Amps) :

6A AC

Actuator Finish :

Nickel

Current Rating :

6A

Illumination Type :

Illuminated

Depth :

44mm

Actuator Material :

Brass

Factory Lead Time :

8 Weeks

Contact Current(AC)-Max :

6A

Lead Free :

Lead Free

Contact Style :

Non-Shorting

Termination Style :

Screw Terminal

Index Stops :

Adjustable

Max Operating Temperature :

70°C

Contact Material :

Phosphor Bronze

Min Operating Temperature :

-10°C

Published :

2012

Voltage - Rated DC :

250V

Number of Positions :

2 ~ 11

Depth Behind Panel :

34.00mm

Contact Timing :

Non-Shorting (BBM)

Actuator Type :

Flatted (6mm Dia)

Index Angle :

30 °

Throw Configuration :

DP, DP12T, SP11T

Actuator Length :

15.60mm

RoHS Status :

ROHS3 Compliant

Max Current Rating :

6A

Operating Force :

28gfm

Mounting Type :

Panel Mount

Circuit per Deck :

SP11T

Pbfree Code :

yes

Terminal Material :

Copper

REACH SVHC :

No SVHC

Number of Decks :

2

JESD-609 Code :

e4

Max Voltage Rating (AC) :

250V

Series :

TS

Voltage - Rated AC :

125V

Termination :

Screw

Terminal Finish :

Silver (Ag)

Switch Type :

ROTARY SWITCH

Length :

44mm

Contact Plating :

Brass, Silver

Moisture Sensitivity Level (MSL) :

1 (Unlimited)

Mount :

Panel

Insulation Resistance :

200mOhm
