TM5RF1-44(71)

Manufacturer :

Hirose

Product Category :

Modular Connector Jacks

Rated Current (Signal) :

0.5A

Packaging :

Tray

Mount :

Through Hole

Connector Type :

JACK

Shielding :

Unshielded

Reference Standard :

UL

Feature :

Board Lock

Insulator Color :

Gray

Reliability :

COMMERCIAL

Contact Style :

TELCOM, MODULAR

PCB Contact Pattern :

STAGGERED

RoHS Status :

RoHS Compliant

Number of Ports :

1

LED Color :

Does Not Contain LED

Insulation Material :

POLYBUTYLENE TEREPHTHALATE

Operating Temperature (Min) :

-25°C

Termination :

Solder

Factory Lead Time :

10 Weeks

Contact Gender :

Male

Number of Positions/Contacts :

4p4c (RJ9, RJ10, RJ22)

Body Breadth :

0.433 inch

Series :

TM-DS

Moisture Sensitivity Level (MSL) :

1 (Unlimited)

Mounting Type :

Through Hole

Terminal Pitch :

2.0066mm

Durability :

200 Cycles

Tab Direction :

Side

Orientation :

90° Angle (Right)

Body Length or Diameter :

0.787 inch

Operating Temperature (Max) :

60°C

Total Number of Contacts :

4

Reach Compliance Code :

Unknown
