TCND3000

Manufacturer :

Vishay

Product Category :

Optical Sensors - Reflective - Analog Output

Forward Voltage :

1.3V

Series :

HALIOS®

Sensing Method :

Reflective

Peak Wavelength :

885 nm

Operating Temperature :

-40°C~85°C

Lead Free :

Lead Free

Width :

2.54mm

Published :

2004

Output Current :

5.6μA

Number of Pins :

4

Termination :

SMD/SMT

Moisture Sensitivity Level (MSL) :

1 (Unlimited)

Reverse Voltage (DC) :

5V

Min Operating Temperature :

-40°C

Max Power Dissipation :

180mW

Output Type :

PIN PHOTODIODE

Number of Channels :

1

Input Current :

50mA

Power Dissipation :

180mW

Packaging :

Tape and Reel (TR)

Wavelength :

885 nm

Length :

4.83mm

Mount :

Surface Mount

Current - DC Forward (If) (Max) :

50mA

Height :

2.21mm

Forward Current :

50mA

RoHS Status :

ROHS3 Compliant

Mounting Type :

Surface Mount

REACH SVHC :

Unknown

Sensing Distance :

0.394 ~ 0.787 (10mm ~ 20mm) ADJ

Max Operating Temperature :

85°C

Package / Case :

4-SMD, No Lead
