SP-52
Or copy the link below:
- Mfr.Part #
- SP-52
- Manufacturer
- Triad Magnetics
- Package / Case
- Datasheet
- Download
- Description
- TRANSER 1.5K CT/ 600 OHM AUDIO
- Stock
- 1,203
- In Stock ：
- 1,203
Request A Quote(RFQ)
- * Fullname:
- * Company:
- * E-Mail:
- Phone:
- Comment:
- * Quantity:
- Manufacturer :
- Triad Magnetics
- Product Category :
- Audio Transformers
- Size / Dimension :
- 0.410Lx0.310W 10.41mmx7.87mm
- Moisture Sensitivity Level (MSL) :
- Not Applicable
- Termination :
- PC Pin
- Mount :
- Through Hole
- Width :
- 10.4mm
- Frequency Response :
- ±2dB
- Height Seated (Max) :
- 0.465 11.80mm
- REACH SVHC :
- Unknown
- Frequency :
- 100kHz
- Impedance - Secondary (Ω) :
- 600
- Mounting Type :
- Through Hole
- Current Rating :
- 3mA
- Voltage - Isolation :
- 1000VRMS @ 1 Second
- Operating Temperature :
- -40°C~85°C
- Weight :
- 11.339809g
- Published :
- 2007
- Output Power :
- 50mW
- Power Rating :
- 50mW
- Length :
- 10.41mm
- Transformer Type :
- Audio Coupling
- DC Resistance (DCR) - Secondary :
- 92Ohm
- Max Frequency :
- 100kHz
- Number of Pins :
- 5
- RoHS Status :
- ROHS3 Compliant
- Power Level :
- 50mW
- DC Resistance (DCR) - Primary :
- 168Ohm
- Impedance - Primary (Ω) :
- 1.5kCT
- Turns Ratio - Primary:Secondary :
- 1.58:1
- Height :
- 11.811mm
- Factory Lead Time :
- 17 Weeks
- Frequency Range :
- 300Hz~100kHz
- DC Resistance (DCR) :
- 168Ohm
- Lead Free :
- Lead Free
- Current :
- 3mA
- Series :
- Red-Spec
- Termination Style :
- PC Pin
- Packaging :
- Bulk
- Datasheets
- SP-52
