PYB30-Q24-T312-U

Manufacturer :

Bel

Product Category :

Operating Temperature :

-40°C~85°C

Package / Case :

Module

Moisture Sensitivity Level (MSL) :

1 (Unlimited)

Input Voltage-Nom :

24V

Type :

Enclosed

Current - Output 1 :

3.5A

Current - Output (Max) :

3.5A 625mA 625mA

Packaging :

Tray

Terminal Position :

UNSPECIFIED

Pbfree Code :

yes

Number of Outputs :

3

Factory Lead Time :

13 Weeks

Output Power :

26.5W

Lead Free :

Lead Free

Voltage - Input (Min) :

9V

Terminal Form :

UNSPECIFIED

Efficiency :

85%

Max Power Dissipation :

30W

Height :

19.05mm

Voltage - Output 3 :

-12V

Current - Output 2 :

625mA

Size / Dimension :

2.66Lx2.16W x 0.75 H 67.5mmx55.0mmx19.1mm

Number of Functions :

1

Mount :

Chassis Mount

Voltage - Input (Max) :

36V

JESD-30 Code :

R-MXFM-X8

RoHS Status :

RoHS Compliant

Trim/Adjustable Output :

No

Output Voltage :

3.3V

Published :

2016

Current - Output 3 :

625mA

Weight :

58.000006g

Mounting Type :

Chassis Mount

Voltage - Output 1 :

3.3V

Approval Agency :

EN, IEC

Voltage - Output 2 :

12V

Number of Terminations :

8

Series :

PYB30-U (30W)
