PYB30-Q24-T312

Manufacturer :

Bel

Product Category :

Size / Dimension :

2.00Lx1.60W x 0.47 H 50.8mmx40.6mmx11.8mm

ECCN Code :

EAR99

Max Power Dissipation :

27W

Lead Free :

Lead Free

Height :

11.938mm

Factory Lead Time :

13 Weeks

Width :

40.6mm

Voltage - Input (Max) :

36V

Peak Reflow Temperature (Cel) :

NOT SPECIFIED

Weight :

49.999997g

Max Output Current :

3.5A

Pbfree Code :

yes

Terminal Position :

Dual

Voltage - Output 2 :

12V

JESD-30 Code :

R-MDMA-P7

Length :

50.8mm

Mount :

Through Hole

Control Features :

Enable, Active High

RoHS Status :

RoHS Compliant

Number of Outputs :

3

Total Power Output-Max :

26.5W

Number of Functions :

1

Voltage - Output 1 :

3.3V

Mounting Type :

Through Hole

Isolation :

Isolated

Operating Temperature :

-40°C~85°C

Voltage - Output 3 :

-12V

Output Voltage :

12V

Applications :

ITE (Commercial)

Type :

Isolated Module

Voltage - Isolation :

1.5kV

Moisture Sensitivity Level (MSL) :

1 (Unlimited)

Trim/Adjustable Output :

No

Voltage - Input (Min) :

9V

Time@Peak Reflow Temperature-Max (s) :

NOT SPECIFIED

Efficiency :

85%

Packaging :

Tube

Current - Output (Max) :

3.5A 625mA 625mA

Input Voltage-Nom :

24V

Terminal Form :

PIN/PEG

Output Power :

30W

Feature :

Remote On/Off, OCP, OVP, SCP, UVLO

Published :

2016

Package / Case :

7-DIP Module

Series :

PYB30 (30W)

Qualification Status :

Not Qualified

Number of Terminations :

7
