PQ1L253M2SP

Manufacturer :

Sharp Microelectronics

Product Category :

Voltage Regulators - DC DC Switching Regulators

Terminal Finish :

Tin/Lead (Sn/Pb)

Min Operating Temperature :

-30°C

Output Current :

300mA

Input Voltage (Min) :

3.5V

Terminal Position :

Dual

Dropout Voltage :

300mV

Length :

4.5mm

JESD-609 Code :

e0

Qualification Status :

Not Qualified

Input Voltage (Max) :

8.5V

Packaging :

Cut Tape (CT)

Terminal Form :

Flat

Number of Functions :

1

Time@Peak Reflow Temperature-Max (s) :

NOT SPECIFIED

Lead Free :

Contains Lead

Regulator Type :

FIXED POSITIVE SINGLE OUTPUT STANDARD REGULATOR

Number of Regulators :

1

Mount :

Surface Mount

RoHS Status :

Non-RoHS Compliant

Reach Compliance Code :

Unknown

Output Voltage :

2.5V

Peak Reflow Temperature (Cel) :

240

Max Operating Temperature :

80°C

Width :

2.5mm

Moisture Sensitivity Level (MSL) :

1 (Unlimited)

Package / Case :

SOT-89-5

Output Voltage 1 :

2.5V

JESD-30 Code :

R-PDSO-F6

Number of Terminations :

6

Published :

2001
