PC12311YFZ0X

Manufacturer :

Sharp Microelectronics

Product Category :

Optoisolators - Transistor, Photovoltaic Output

Number of Channels :

1

Mounting Type :

Through Hole

Current - DC Forward (If) (Max) :

10mA

Vce Saturation (Max) :

200mV

Power Dissipation :

170mW

Current - Output / Channel :

50mA

Moisture Sensitivity Level (MSL) :

1 (Unlimited)

Rise Time :

4μs

Output Type :

Transistor

Number of Pins :

4

Operating Temperature :

-30°C~100°C

Supplier Device Package :

4-DIP

Voltage - Forward (Vf) (Typ) :

1.2V

Fall Time (Typ) :

3 μs

Current Transfer Ratio (Max) :

250% @ 500μA

Input Type :

DC

Packaging :

Tube

Mount :

Through Hole

Voltage - Isolation :

5000Vrms

Collector Emitter Voltage (VCEO) :

200mV

Voltage - Output (Max) :

70V

Rise / Fall Time (Typ) :

4μs 3μs

Package / Case :

4-DIP (0.300, 7.62mm)

Current Transfer Ratio (Min) :

100% @ 500μA

Output Current per Channel :

1.25mA

Output Voltage :

70V

RoHS Status :

RoHS Compliant
