OPIA2110ATRE

Manufacturer :

TT Electronics

Product Category :

Optoisolators - Transistor, Photovoltaic Output

RoHS Status :

RoHS Compliant

Configuration :

Single

Rise Time :

20μs

Package / Case :

6-SMD, Gull Wing

Collector Emitter Saturation Voltage :

300mV

Current Transfer Ratio (Max) :

400% @ 10mA

Output Type :

Transistor

Number of Pins :

8

Mounting Type :

Surface Mount

Fall Time (Typ) :

20 μs

Input Type :

DC

Reverse Breakdown Voltage :

5V

Additional Feature :

UL RECOGNIZED, VDE APPROVED

Forward Current :

25mA

Voltage - Isolation :

5000Vrms

Output Voltage :

60V

Input Current :

50mA

Collector Emitter Voltage (VCEO) :

60V

Moisture Sensitivity Level (MSL) :

1 (Unlimited)

Number of Elements :

1

Max Power Dissipation :

150mW

Max Collector Current :

50mA

Rise / Fall Time (Typ) :

4μs 3μs

Current Transfer Ratio (Min) :

40% @ 10mA

Output Current per Channel :

50mA

Published :

2010

Operating Temperature :

-55°C~125°C

Voltage - Forward (Vf) (Typ) :

1.2V

Mount :

Surface Mount

Packaging :

Tape and Reel (TR)

Power Dissipation :

100mW

Number of Channels :

1
