N10226-5212PC

Manufacturer :

3M

Product Category :

Centronics Connectors

Sensing Distance :

3 m

Current Rating :

1A

Mount :

Panel, Through Hole

Contact Plating :

Gold

Flammability Rating :

UL94 V-0

Contact Finish :

Gold

Published :

2000

RoHS Status :

RoHS Compliant

Connector Style :

Outer Shroud Contacts

Length :

37.2mm

Housing Color :

Beige

Contact Material :

Copper

Lead Free :

Lead Free

Pitch :

2.54mm

Series :

102, Mini D Ribbon (MDR)

Plating :

Gold

Mounting Type :

Panel Mount, Through Hole, Right Angle

Number of Terminations :

26

Depth :

16.7mm

REACH SVHC :

No SVHC

Number of Rows :

2

Orientation :

RIGHT ANGLE

Max Current Rating :

1A

Connector Type :

Receptacle

Feature :

Shielded

Number of Ports :

1

Lead Length :

3m

Max Operating Temperature :

105°C

Moisture Sensitivity Level (MSL) :

1 (Unlimited)

Number of Contacts :

26

Width :

13.9mm

Factory Lead Time :

14 Weeks

Housing Material :

Polychlorinated

Termination :

Solder

Cable Length :

3m

Flange Feature :

Housing/Shell (M2.6)

Gender :

Receptacle

Min Operating Temperature :

-55°C

Insulation Material :

Glass

Number of Positions :

26

Contact Finish Thickness :

30.0μin 0.76μm
