MV54164

Manufacturer :

Everlight Electronics

Product Category :

Lens Style :

Round with Domed Top

Configuration :

Bar - 10 Wide, DIP

Wavelength - Peak :

562nm

Forward Current :

30mA

Packing Method :

Bulk

Reverse Voltage :

6V

Max Operating Temperature :

85°C

Package / Case :

DIP

Additional Feature :

IC COMPATIBLE

Power Dissipation :

750mW

Luminous Intensity :

2.5 mcd

Packaging :

Tube

Published :

2005

Min Operating Temperature :

-40°C

Number of Elements :

10

Voltage - Rated :

2.2V

Length :

25.53mm

Forward Voltage :

3V

Mount :

Through Hole

Millicandela Rating :

1.8mcd

Lens Size :

5.00mm Dia

Shape :

RECTANGULAR

Terminal Pitch :

7.62mm

Overall Height :

8mm

Factory Lead Time :

12 Weeks

Test Current :

10mA

Number of Functions :

1

Radiation Hardening :

No

Pbfree Code :

yes

Number of Pins :

20

Series :

MV5x164

Moisture Sensitivity Level (MSL) :

1 (Unlimited)

Depth :

10.16mm

RoHS Status :

ROHS3 Compliant

Mounting Type :

Through Hole

Illumination Color :

Green

Optoelectronic Device Type :

SINGLE COLOR LED ARRAY

Color :

Green (x 10)

Display Type :

BAR GRAPH

Number of Terminations :

20

Number of LEDs :

10

Lead Free :

Lead Free
