MPX2200AP
Or copy the link below:
- Mfr.Part #
- MPX2200AP
- Manufacturer
- NXP Semiconductors
- Package / Case
- 4-SIP Module
- Datasheet
- Download
- Description
- SENSOR ABS PRESS 29PSI MAX
- Stock
- 9
- In Stock ：
- 9
Request A Quote(RFQ)
- * Fullname:
- * Company:
- * E-Mail:
- Phone:
- Comment:
- * Quantity:
- Manufacturer :
- NXP Semiconductors
- Product Category :
- Pressure Sensors, Transducers
- Port Style :
- Barbed
- Factory Lead Time :
- 12 Weeks
- HTS Code :
- 8542.39.00.01
- Accuracy :
- ±1%
- Offset-Nom :
- 0V
- Sensors/Transducers Type :
- PRESSURE SENSOR,PEIZORESISTIVE
- ECCN Code :
- EAR99
- Output :
- 0 mV ~ 40 mV (10V)
- Termination Style :
- PC Pin
- Pressure Range-Max :
- 29 Psi
- Operating Pressure :
- 29.01PSI (200kPa)
- Voltage - Supply :
- 10V~16V
- Body Breadth :
- 17.78 mm
- Moisture Sensitivity Level (MSL) :
- Not Applicable
- Sensitivity (mV/V) :
- 0.2 mV/V
- RoHS Status :
- ROHS3 Compliant
- Body Height :
- 12.19mm
- Body Length or Diameter :
- 29.47mm
- Mounting Feature :
- THROUGH HOLE MOUNT
- Output Type :
- Wheatstone Bridge
- Response Time :
- 1000 μs
- Surface Mount :
- No
- Pressure Type :
- Absolute
- Package / Case :
- 4-SIP Module
- Operating Temperature :
- -40°C~125°C
- Port Size :
- Male - 0.19 4.93mm Tube
- Feature :
- Temperature Compensated
- Applications :
- Board Mount
- Maximum Pressure :
- 116.03PSI (800kPa)
- Housing :
- Plastic
- Series :
- MPX2200
- Linearity :
- 1 %
- Published :
- 1998
- Datasheets
- MPX2200AP
MPX2200AP Documents
MPX2200 Series Absolute Pressure Sensor Wheatstone Bridge -40°C~125°C 29.01PSI (200kPa) Barbed ±1% 0 mV ~ 40 mV (10V) 10V~16V Temperature Compensated
MPX2200AP Overview
As a convenience, the transducer is included in the package 4-SIP Module. Ensure reliable performance by setting the transducers to -40°C~125°C. With a supply voltage of 10V~16V, the transducers can operate efficiently. There is a maximum range of pressure set by this transducer of 29 Psi.
MPX2200AP Features
Moisture Sensitivity Level: Not Applicable
Package / Case: 4-SIP Module
Operating Temperature: -40°C~125°C
MPX2200 series
Sensitivity (mV/V): 0.2 mV/V
Operating Pressure: 29.01PSI (200kPa)
MPX2200AP Applications
There are a lot of NXP USA Inc.
MPX2200AP Transducers applications.
- Virtual Reality and Gaming Equipment
- Indoor/Outdoor Navigation (dead-reckoning, floor/elevator/step detection)
- Vertical velocity monitoring
- Leisure, Sports, and Fitness Activity Identification
- Weather Forecasting
- Hydrogen Storage
- Refrigerant pressure monitoring in HVAC/R systems
- Dry air system pressure, process controls and automation
- Dry air system monitoring
- Hydraulic, brake, and engine oil fluid pressure monitoring
