MC68030FE20C

Manufacturer :

NXP Semiconductors

Product Category :

Microprocessors

Voltage - I/O :

5.0V

Series :

M680x0

Qualification Status :

COMMERCIAL

Pin Count :

132

External Data Bus Width :

32

Number of Cores/Bus Width :

1 Core 32-Bit

Surface Mount :

yes

Packaging :

Tray

Clock Frequency :

20MHz

Speed :

20MHz

Moisture Sensitivity Level (MSL) :

1 (Unlimited)

Number of Terminations :

132

Integrated Cache :

No

Time@Peak Reflow Temperature-Max (s) :

40

Boundary Scan :

No

Supply Voltage :

5V

Low Power Mode :

No

Core Processor :

68030

Terminal Pitch :

0.635mm

Supply Voltage-Min (Vsup) :

4.75V

uPs/uCs/Peripheral ICs Type :

MICROPROCESSOR

Address Bus Width :

32

Graphics Acceleration :

No

Terminal Position :

QUAD

Format :

FIXED POINT

Height Seated (Max) :

4.31mm

Bit Size :

32

Operating Temperature :

0°C~70°C TA

Package / Case :

132-BCQFP

Additional Interfaces :

SCI, SPI

Peak Reflow Temperature (Cel) :

260

Length :

22.355mm

RoHS Status :

ROHS3 Compliant

Terminal Form :

Gull wing

JESD-30 Code :

S-CQFP-G132

Supply Voltage-Max (Vsup) :

5.25V
