LXZ1-PL01
- Mfr.Part #
- LXZ1-PL01
- Manufacturer
- Lumileds
- Package / Case
- 0705 (1713 Metric)
- Datasheet
- Download
- Description
- LED LUXEON Z AMBER 590NM SMD
- Stock
- 41,184
- In Stock :
- 41,184
Request A Quote(RFQ)
- * Fullname:
- * Company:
- * E-Mail:
- Phone:
- Comment:
- * Quantity:
- Manufacturer :
- Lumileds
- Product Category :
- Mount :
- Surface Mount
- Size / Dimension :
- 0.067Lx0.051W 1.70mmx1.30mm
- Moisture Sensitivity Level (MSL) :
- 1 (Unlimited)
- Dominant Wavelength :
- 590 nm
- Optoelectronic Device Type :
- SINGLE COLOR LED
- Packaging :
- Cut Tape (CT)
- Number of Terminations :
- 2
- Luminous Flux :
- 66 lm
- Published :
- 2012
- Wavelength :
- 590nm 585nm ~ 595nm
- Height :
- 960μm
- Number of LEDs :
- 16
- Temperature - Test :
- 25°C
- Color :
- Amber
- Min Operating Temperature :
- -40°C
- Packing Method :
- TAPE AND REEL 13"
- Current - Max :
- 700mA
- Number of Functions :
- 1
- Lens Style :
- Rectangular, Round
- Number of Pins :
- 2
- Voltage - Forward (Vf) (Typ) :
- 2.15V
- Max Operating Temperature :
- 120°C
- Lead Free :
- Lead Free
- Series :
- LUXEON Z
- Lens Color :
- Orange
- Lumens/Watt @ Current - Test :
- 52 lm/W
- Flux @ Current/Temperature - Test :
- 56lm 48lm~64lm
- Mounting Type :
- Surface Mount
- Package / Case :
- 0705 (1713 Metric)
- Height Seated (Max) :
- 0.026 0.66mm
- Thermal Resistance of Package :
- 8°C/W
- Forward Current :
- 500mA
- RoHS Status :
- RoHS Compliant
- Viewing Angle :
- 145°
- Configuration :
- Single
- Factory Lead Time :
- 8 Weeks
