LP2982AIM5-3.3

Manufacturer :

Texas Instruments

Product Category :

Voltage Regulators - Linear

Lead Free :

Lead Free

Max Supply Voltage :

16V

Thickness :

1.2mm

Terminal Form :

Gull wing

Min Current Limit :

100mA

PSRR :

45dB (1kHz)

Number of Functions :

1

Termination :

SMD/SMT

Height :

1.45mm

Output Type :

FIXED

RoHS Status :

ROHS3 Compliant

Output Voltage 1 :

3.3V

Min Supply Voltage :

2.1V

Max Output Current :

150mA

Number of Outputs :

1

Voltage Tolerance-Max :

2%

Output Voltage :

3.3V

Factory Lead Time :

6 Weeks

Mounting Type :

Surface Mount

Base Part Number :

LP2982

Min Input Voltage :

2.1V

Nominal Output Voltage :

3.3V

Peak Reflow Temperature (Cel) :

260

Number of Terminations :

5

Width :

1.6mm

Dropout Voltage1-Nom :

0.12V

Packaging :

Cut Tape (CT)

Protection Features :

Over Current, Over Temperature, Short Circuit

JESD-609 Code :

e3

Control Features :

Enable

Moisture Sensitivity Level (MSL) :

1 (Unlimited)

Number of Regulators :

1

Number of Pins :

5

Dropout Voltage :

120mV

Terminal Position :

Dual

Operating Temperature :

-40°C~125°C

Length :

2.9mm

Packing Method :

TR

Voltage Dropout (Max) :

0.33V @ 80mA

Current - Quiescent (Iq) :

95μA

Current - Output :

50mA

Pin Count :

5

Pbfree Code :

yes

Max Output Voltage :

3.3V

Contact Plating :

Tin

REACH SVHC :

No SVHC

Package / Case :

SC-74A, SOT-753

Lifecycle Status :

ACTIVE (Last Updated: 5 days ago)

Output Configuration :

Positive

Current - Supply (Max) :

1.4mA

Quiescent Current :

65μA

Voltage - Input (Max) :

16V

Accuracy :

1.5 %

Radiation Hardening :

No

Mount :

Surface Mount

ECCN Code :

EAR99
