LM258WYPT

Manufacturer :

STMicroelectronics

Product Category :

Instrumentation, OP Amps, Buffer Amps

Slew Rate :

0.6V/µs

Terminal Finish :

Matte Tin (Sn)

Number of Circuits :

2

Low-Bias :

No

Package / Case :

8-TSSOP (0.173, 4.40mm Width)

Power :

No

Architecture :

VOLTAGE-FEEDBACK

Amplifier Type :

GENERAL PURPOSE

Operating Supply Voltage :

30V

Programmable Power :

No

Lifecycle Status :

ACTIVE (Last Updated: 7 months ago)

Height :

1.05mm

RoHS Status :

ROHS3 Compliant

Input Offset Voltage (Vos) :

1mV

Pin Count :

8

Number of Functions :

2

Terminal Form :

Gull wing

Output Current per Channel :

60mA

JESD-609 Code :

e3

Max Frequency :

100kHz

Bias Current-Max (IIB) @25C :

0.15μA

Unity Gain BW-Nom :

1100 kHz

Wideband :

No

Peak Reflow Temperature (Cel) :

260

Packaging :

Tape and Reel (TR)

Frequency Compensation :

yes

Power Supplies :

5V

Operating Temperature :

-40°C~105°C

Base Part Number :

LM258

Mount :

Surface Mount

Length :

3.1mm

Series :

Automotive, AEC-Q100

Current - Input Bias :

20nA

Packing Method :

Tape and Reel

Gain Bandwidth Product :

1.1MHz

Common-mode Reject Ratio-Min :

60 dB

Common Mode Rejection Ratio :

85 dB

Input Offset Current-Max (IIO) :

0.04μA

Width :

4.5mm

Moisture Sensitivity Level (MSL) :

1 (Unlimited)

Number of Pins :

8

Micropower :

No

Supply Voltage :

5V

Number of Terminations :

8

Operating Supply Current :

700µA

ECCN Code :

EAR99

Qualification Status :

Not Qualified

Time@Peak Reflow Temperature-Max (s) :

30

Terminal Position :

Dual

Low-Offset :

No

Factory Lead Time :

14 Weeks

Terminal Pitch :

0.65mm

Voltage - Supply, Single/Dual (±) :

3V~30V ±1.5V~15V

Mounting Type :

Surface Mount
