KB-17AG-120

Share

Or copy the link below:

Mfr.Part #
KB-17AG-120
Manufacturer
TE Connectivity Potter & Brumfield Relays
Package / Case
120
Datasheet
Download
Description
RELAY GEN PURPOSE 4PDT 10A 120V
Stock
37,772
In Stock :
37,772

Request A Quote(RFQ)

* Fullname:
* Company:
* E-Mail:
  Phone:
  Comment:
* Quantity:
Manufacturer :
TE Connectivity Potter & Brumfield Relays
Product Category :
Power Relays, Over 2 Amps
Contact/Output Supply Type :
AC
Lifecycle Status :
ACTIVE (Last Updated: 1 day ago)
Physical Dimension :
81.79mm x 46.02mm x 36.01mm
Lead Free :
Lead Free
Coil Type :
Latching, Dual Coil
Body Breadth :
46.02 mm
Height :
36mm
Coil Resistance :
1.03kOhm
Contact Voltage Rating (AC) :
120V
Throw Configuration :
4PDT
Contact Form :
4PDT (4 Form C)
Termination :
Solder
Contact Rating (Current) :
10A
Packaging :
Bulk
Insulation Resistance :
100000000Ohm
Dielectric Strength Between Open Contacts :
500 Vrms
Electrical Life :
500000 Cycle(s)
Length :
81.8mm
Number of Pins :
20
Termination Style :
Solder Lug
Coil Voltage :
120VAC
ECCN Code :
EAR99
Operating Temperature :
-45°C~85°C
Reference Standard :
UL
Mount :
Panel
Dielectric Strength Between Coil and Contacts :
1000 Vrms
Relay Action :
LATCHED
ELV :
Non-Compliant
REACH SVHC :
Unknown
Package / Case :
120
Width :
46mm
Coil Voltage (AC) :
120V
Factory Lead Time :
23 Weeks
Must Operate Voltage :
102VAC
Contact Material :
Silver Cadmium Oxide (AgCdO)
Switching Voltage :
120VAC -Max
Published :
2011
Additional Feature :
COIL OPERATE VOLTAGE(AC): 102 V
Moisture Sensitivity Level (MSL) :
1 (Unlimited)
Series :
KB
Weight :
306.004753g
Coil Power :
5.3W
Relay Type :
GENERAL PURPOSE
RoHS Status :
RoHS Compliant
Max Voltage Rating (AC) :
120V
Coil Current :
44mA
Mounting Type :
Chassis Mount
Coil/Input Supply Type :
AC
Sealing :
Hermetically Sealed
Operate Time :
25 ms
Datasheets
KB-17AG-120
Introducing Power Relays, Over 2 Amps TE Connectivity Potter & Brumfield Relays KB-17AG-120 from Chip IC,where excellence meets affordability. This product stands out with its Number of Pins:20, Operating Temperature:-45°C~85°C, Package / Case:120, Mounting Type:Chassis Mount, KB-17AG-120 pinout, KB-17AG-120 datasheet PDF, KB-17AG-120 amp .Beyond Power Relays, Over 2 Amps TE Connectivity Potter & Brumfield Relays KB-17AG-120 ,we also offer MY4 DC24 (S), MY4 DC12 (S), ST2-DC5V-F, Our vast inventory has you covered. Contact us now for immediate solutions.
