HOA2862-002

Manufacturer :

Honeywell Sensing and Productivity Solutions

Product Category :

Optical Sensors - Photointerrupters - Slot Type - Transistor Output

Package / Case :

Module, Slotted

RoHS Status :

RoHS Compliant

Number of Elements :

1

Min Operating Temperature :

-55°C

Max Operating Temperature :

100°C

Reverse Breakdown Voltage :

3V

Collector Emitter Voltage (VCEO) :

30V

Number of Pins :

4

Moisture Sensitivity Level (MSL) :

1 (Unlimited)

Current - DC Forward (If) (Max) :

50mA

Max Collector Current :

30mA

Dark Current :

100nA

Forward Current :

50mA

Response Time :

15μs

Sensing Method :

Through-Beam

Mounting Type :

Through Hole

Sensing Distance :

0.100 (2.54mm)

Rise Time :

15μs

Mount :

Through Hole

Collector Emitter Saturation Voltage :

400mV

Factory Lead Time :

14 Weeks

Power Dissipation :

75mW

Packaging :

Bulk

Housing Material :

Polyester

Forward Voltage :

1.6V

Current - Collector (Ic) (Max) :

30mA

Fall Time (Typ) :

15 µs

Collector Emitter Breakdown Voltage :

30V

Output Configuration :

Phototransistor

Published :

1997

Voltage - Collector Emitter Breakdown (Max) :

30V

Operating Temperature :

-55°C~100°C

Type :

Unamplified
