ES2B

Manufacturer :

Diotec Semiconductor

Product Category :

Diodes - Rectifiers - Single

Published :

2017

Capacitance @ Vr, F :

18pF @ 4V 1MHz

REACH SVHC :

No SVHC

Voltage - Forward (Vf) (Max) @ If :

900mV @ 2A

Mounting Type :

Surface Mount

Operating Temperature - Junction :

-55°C~150°C

Voltage - Rated DC :

100V

Current Rating :

2A

Max Operating Temperature :

150°C

Forward Voltage :

900mV

Average Rectified Current :

2A

Peak Reverse Current :

10μA

Number of Pins :

2

Speed :

Fast Recovery =< 500ns, > 200mA (Io)

Output Current :

2A

RoHS Status :

ROHS3 Compliant

Lead Free :

Lead Free

Diode Type :

Standard

Capacitance :

18pF

Max Repetitive Reverse Voltage (Vrrm) :

100V

Current - Average Rectified (Io) :

2A

Reverse Recovery Time :

20 ns

Package / Case :

DO-214AA, SMB

Base Part Number :

ES2B

Factory Lead Time :

10 Weeks

Forward Current :

2A

Max Forward Surge Current (Ifsm) :

50A

Power Dissipation :

1.66W

Current - Reverse Leakage @ Vr :

10μA @ 100V

Polarity :

Standard

Mount :

Surface Mount

Radiation Hardening :

No

Packaging :

Tape and Reel (TR)

Moisture Sensitivity Level (MSL) :

1 (Unlimited)

Length :

4.75mm

Voltage - DC Reverse (Vr) (Max) :

100V

Max Reverse Voltage (DC) :

100V

Min Operating Temperature :

-55°C

Peak Non-Repetitive Surge Current :

50A

Recovery Time :

20 ns

Element Configuration :

Single

Width :

3.95mm

Weight :

180mg

Height :

2.45mm

Lifecycle Status :

ACTIVE (Last Updated: 2 days ago)

Supplier Device Package :

DO-214AA (SMB)

Max Surge Current :

50A

Reverse Voltage :

100V
