ES1J

Manufacturer :

SURGE

Product Category :

Diodes - Rectifiers - Single

Current :

1A

Max Junction Temperature (Tj) :

150°C

Packaging :

Tape and Reel (TR)

Supplier Device Package :

SMA (DO-214AC)

Factory Lead Time :

10 Weeks

Reverse Voltage :

600V

Mount :

Surface Mount

Forward Current :

1A

Average Rectified Current :

1A

Speed :

Fast Recovery =< 500ns, > 200mA (Io)

Length :

4.6mm

Capacitance @ Vr, F :

8pF @ 0V 1MHz

Voltage - DC Reverse (Vr) (Max) :

600V

REACH SVHC :

No SVHC

Recovery Time :

35 ns

Package / Case :

DO-214AC, SMA

Peak Non-Repetitive Surge Current :

30A

Element Configuration :

Single

Max Reverse Voltage (DC) :

600V

Diode Type :

Standard

Current - Average Rectified (Io) :

1A

Voltage :

600V

Base Part Number :

ES1J

RoHS Status :

ROHS3 Compliant

Operating Temperature - Junction :

150°C Max

Reverse Recovery Time :

35 ns

Capacitance :

10pF

Current - Reverse Leakage @ Vr :

5µA @ 600V

Max Forward Surge Current (Ifsm) :

30A

Moisture Sensitivity Level (MSL) :

1 (Unlimited)

Width :

2.896mm

Lifecycle Status :

ACTIVE (Last Updated: 4 days ago)

Number of Pins :

2

Voltage - Forward (Vf) (Max) @ If :

1.7V @ 1A

Mounting Type :

Surface Mount

Max Surge Current :

30A

Lead Free :

Lead Free

Termination :

SMD/SMT

Min Operating Temperature :

-55°C

Radiation Hardening :

No

Max Operating Temperature :

150°C

Peak Reverse Current :

5μA

Height :

2.5mm

Published :

2006

Contact Plating :

Tin

Max Repetitive Reverse Voltage (Vrrm) :

600V

Forward Voltage :

1.7V
