EPF10K30AFC484-1

Manufacturer :

Altera

Product Category :

FPGAs (Field Programmable Gate Array)

Mounting Type :

Surface Mount

ECCN Code :

3A991

Qualification Status :

Not Qualified

Moisture Sensitivity Level (MSL) :

3 (168 Hours)

Base Part Number :

EPF10K30

HTS Code :

8542.39.00.01

Series :

FLEX-10KA®

Number of Logic Elements/Cells :

1728

Number of Terminations :

484

Surface Mount :

yes

Width :

23mm

Package / Case :

484-BBGA

RoHS Status :

Non-RoHS Compliant

Number of Dedicated Inputs :

4

Clock Frequency :

80MHz

Height Seated (Max) :

2.1mm

Number of Gates :

69000

Programmable Logic Type :

LOADABLE PLD

Terminal Position :

BOTTOM

Terminal Form :

Ball

Voltage - Supply :

3V~3.6V

Supply Voltage :

3.3V

Operating Temperature :

0°C~70°C TA

JESD-609 Code :

e0

Number of Inputs :

246

Terminal Finish :

Tin/Lead (Sn/Pb)

Number of LABs/CLBs :

216

Length :

23mm

Propagation Delay :

0.6 ns

Number of I/O :

246

Peak Reflow Temperature (Cel) :

220

Number of Outputs :

246

Time@Peak Reflow Temperature-Max (s) :

30

Packaging :

Tray

Output Function :

REGISTERED

Power Supplies :

2.5/3.33.3V

JESD-30 Code :

S-PBGA-B484

Terminal Pitch :

1mm

Total RAM Bits :

12288
