EM279502H

Manufacturer :

Eaton-Electronics Division

Product Category :

Wire to Board

Moisture Sensitivity Level (MSL) :

1 (Unlimited)

Max Operating Temperature :

105°C

Termination :

Solder

Wire Gauge (Min) :

14 AWG

RoHS Status :

RoHS Compliant

Min Operating Temperature :

-40°C

Voltage :

300V

Number of Levels :

1

Length :

12.7mm

Contact Plating :

Brass, Tin

Max Current Rating :

10A

Weight :

2.267962g

Contact Material :

Tin

Pitch :

0.200 5.08mm

Packaging :

Bulk

Max Supply Voltage :

300V

Height :

13.97mm

Current :

10A

Positions Per Level :

2

Number of Contacts :

2

Mount :

Through Hole

Published :

2005

Wire Gauge :

14-24 AWG

Wire Termination :

Screwless - Push Button Clamp

Wire Gauge (Max) :

24 AWG

Number of Poles :

2

Operating Temperature :

-40°C~105°C

Flammability Rating :

UL94 V-0

Number of Rows :

1

Number of Positions :

2

Orientation :

RIGHT ANGLE

Housing Material :

Thermoplastic

Series :

Euro-Mag EM2795

Mounting Type :

Through Hole

Mating Orientation :

Vertical with Board

Voltage - Rated :

300V

Factory Lead Time :

15 Weeks

Number of Positions Per Level :

2

Depth :

13mm

Current Rating :

10A

Lead Free :

Lead Free

Contact Material - Plating :

Brass - Tin Plated
