DSC1004CL2-003.2768T

Manufacturer :

Microchip Technology

Product Category :

Oscillators

Height - Seated (Max) :

0.035 (0.90mm)

Mounting Feature :

Surface Mount

RoHS Status :

ROHS3 Compliant

Mounting Type :

Surface Mount

Supply Voltage :

3.3V

Output Load :

10 KOHM, 40 pF

Moisture Sensitivity Level (MSL) :

1 (Unlimited)

Series :

DSC1004

Current - Supply (Disable) (Max) :

15µA

JESD-609 Code :

e3

Function :

Standby (Power Down)

Voltage - Supply :

1.8V~3.3V

Oscillator Type :

CMOS

Output :

CMOS

Symmetry-Max :

55/45%

Frequency :

3.2768MHz

Ratings :

AEC-Q100

Reach Compliance Code :

Compliant

Size / Dimension :

0.126Lx0.098W 3.20mmx2.50mm

Package :

Tape and Reel (TR)

Physical Dimension :

3.2mm x 2.5mm x 0.85mm

Packaging :

Tape and Reel (TR)

Rise Time-Max :

2ns

Spread Spectrum Bandwidth :

-

Fall Time-Max :

2ns

Manufacturer :

Microchip Technology Inc

Package / Case :

4-VDFN

Type :

XO (Standard)

Operating Frequency :

3.2768MHz

Height Seated (Max) :

0.035 0.90mm

Product Status :

Active

Base Product Number :

DSC1004

Additional Feature :

AEC-Q100; STANDBY; ENABLE/DISABLE FUNCTION; TR; 1.8 AND 2.5V SUPPLY VOLTAGE ALSO AVAILABLE

Terminal Finish :

Matte Tin (Sn)

Current - Supply (Max) :

8mA

Absolute Pull Range (APR) :

±25ppm

Surface Mount :

yes

Frequency Stability :

-

Frequency Adjustment-Mechanical :

No

Base Resonator :

MEMS

Operating Temperature :

-40°C~105°C
