DS1669-50+

Manufacturer :

Dallas Semiconductor

Product Category :

Digital Potentiometers

Number of Positions :

64

Number of Taps :

64

Voltage - Supply :

±4.5V~8V

Additional Feature :

THE VOLTAGE APPLIED TO ANY TERMINAL MUST NOT EXCEED THE -V OR BY 0.5 VOLTS

Length :

9.375mm

Moisture Sensitivity Level (MSL) :

3 (168 Hours)

Package / Case :

8-DIP (0.300, 7.62mm)

Bandwidth :

0.2 kHz

Resistance :

50kOhm

Number of Functions :

1

Configuration :

Potentiometer

Terminal Pitch :

2.54mm

Number of Terminations :

8

Number of Circuits :

1

Mounting Type :

Through Hole

JESD-30 Code :

R-PDIP-T8

Terminal Finish :

TIN LEAD

Memory Type :

Non-Volatile

Terminal Position :

Dual

RoHS Status :

Non-RoHS Compliant

Packaging :

Tube

Peak Reflow Temperature (Cel) :

245

Taper :

Linear

Tolerance :

±20%

Temperature Coefficient :

750 ppm/°C

Time@Peak Reflow Temperature-Max (s) :

NOT SPECIFIED

Surface Mount :

No

Qualification Status :

COMMERCIAL

Interface :

Up/Down (UP, DN)

Resistance - Wiper (Ω) (Typ) :

400

Temperature Coefficient (Typ) :

750ppm/°C

Operating Temperature :

-40°C~85°C

Series :

Dallastat™

JESD-609 Code :

e0

Pbfree Code :

No

Height Seated (Max) :

4.572mm

Pin Count :

8

Width :

7.62mm

Total Resistance :

50000Ohm
