DS-109-PIN
Or copy the link below:
- Mfr.Part #
- DS-109-PIN
- Manufacturer
- MACOM Technology Solutions
- Package / Case
- FP-2
- Datasheet
- Download
- Description
- POWER DIVIDER,2-WAY
- Stock
- 23
- In Stock ：
- 23
Request A Quote(RFQ)
- * Fullname:
- * Company:
- * E-Mail:
- Phone:
- Comment:
- * Quantity:
- Manufacturer :
- MACOM Technology Solutions
- Product Category :
- RF Power Dividers/Splitters
- Input Power-Max (CW) :
- 44.77 dBm
- Product Type :
- Signal Conditioning
- Subcategory :
- Filters
- Construction :
- COMPONENT
- Series :
- -
- Operating Frequency-Max :
- 500 MHz
- RoHS :
- N
- Pbfree Code :
- No
- Manufacturer :
- MACOM
- Rad Hardened :
- No
- Specifications :
- Isolation (Min) 25dB, 1.3 VSWR (Max), 1° Imbalance (Max)
- Base Product Number :
- DS-109
- Package / Case :
- FP-2
- Size / Dimension :
- 0.508" L x 0.386" W x 0.150" H (12.90mm x 9.80mm x 3.80mm)
- Insertion Loss :
- 0.6dB
- Product :
- Power Dividers
- Package Type :
- FP-2
- Product Status :
- Active
- Operating Frequency-Min :
- 10 MHz
- Brand :
- MACOM
- Reach Compliance Code :
- Compliant
- Package :
- Tray
- Frequency :
- 10 MHz ~ 500 MHz
- RF/Microwave Device Type :
- Splitter
- Pin Count :
- 8
- Product Category :
- Signal Conditioning
- Characteristic Impedance :
- 50 Ω
- Screening Level :
- Industrial
- VSWR-Max :
- 1.3
- Datasheets
- DS-109-PIN
