CPC1927J

Manufacturer :

Littelfuse

Product Category :

Solid State Relays

Mounting Style :

PCB Mount

Voltage - Load :

0V~250V

Dimensions :

19.914 x 5.029 x 26.162mm

Brand :

IXYS Integrated Circuits

Moisture Sensitivity Level (MSL) :

1 (Unlimited)

Terminal Finish :

Matte Tin (Sn)

Factory Lead Time :

11 Weeks

Min Operating Temperature :

-40°C

Number of Pins :

264

Forward Current-Max :

0.1 A

RoHS :

Compliant

Product Category :

Solid State Relays - PCB Mount

Radiation Hardening :

No

On-State Resistance (Max) :

200mOhms

Max Output Voltage :

250V

HTS Code :

8541.40.95.00

Maximum Operating Temperature :

+85°C

Base Product Number :

CPC1927

Packaging :

Tube

Optoelectronic Device Type :

TRANSISTOR OUTPUT SSR

RoHS Status :

ROHS3 Compliant

Output Device :

MOSFET

Termination Style :

PC Pin

Mounting Type :

Through Hole

Isolation Voltage :

2.5kV

Product Type :

SSR - Solid State Relays

Termination :

PC Pin

On-State Resistance :

150 mΩ

Package :

Tube

Output Voltage :

250V

Ambient Temperature Range High :

85 °C

Product :

Solid State Relays

Minimum Operating Temperature :

-40°C

Configuration :

Single

Number of Poles :

1

Circuit :

SPST-NO (1 Form A)

Number of Contacts :

1

Voltage - Input :

1.2VDC

Contact Form :

SPST (1 Form A)

Relay Type :

Relay

Contact Configuration :

SPST

Number of Elements :

1

Capacitance :

1.1 nF

Load Current :

2.7A

Manufacturer :

IXYS

Width :

5.029 mm

Output Type :

AC, DC

Terminal Type :

PCB Pin

JESD-609 Code :

e3

Throw Configuration :

SPST

Reach Compliance Code :

Unknown

Max Junction Temperature (Tj) :

100 °C

Resistance :

200mOhm

Supplier Device Package :

ISOPLUS264™

Series :

CPC, OptoMOS®

Special Features :

Arc-Free With No Snubbing Circuits, High Reliability, Low Drive Power Requirement, Machine Insertable, No EMI/RFI Generation, Wave Solderable

Height :

29.159 mm

Mount :

Through Hole

Input Current :

100mA

Length :

19.91mm

Published :

2004

Product Status :

Active

Lead Free :

Lead Free

Package / Case :

ISOPLUS264™

Isolation Voltage-Max :

2500 V

Additional Feature :

UL RECOGNIZED

Subcategory :

Relays

Depth :

5.03mm

Standards Met :

UL 508 Approved File No E69938

Type :

Isolated

Tradename :

Clare

Pbfree Code :

yes

Max Operating Temperature :

85°C

Output Current :

15 A

Operating Temperature Range :

-40 → +85°C

Max Forward Surge Current (Ifsm) :

25 A
