CDF10000LD

Manufacturer :

COILCRAFT

Product Category :

Common Mode Chokes

Ratings :

-

Voltage Rating - DC :

-

Operating Temperature :

-40°C ~ 85°C

Mounting Type :

Surface Mount

Package :

Strip

Approval Agency :

-

Filter Type :

Signal Line

Size / Dimension :

0.362" L x 0.362" W (9.20mm x 9.20mm)

DC Resistance (DCR) (Max) :

250mOhm

Package / Case :

20-BQFN

Number of Lines :

10

Series :

CDF

Current Rating (Max) :

100mA

Height (Max) :

0.165" (4.20mm)

Product Status :

Active

Inductance @ Frequency :

5 µH @ 1 MHz

Voltage Rating - AC :

-

Features :

-

Impedance @ Frequency :

520 Ohms @ 43 MHz
