C67402N
Or copy the link below:
- Mfr.Part #
- C67402N
- Manufacturer
- Advanced Micro Devices
- Package / Case
- 16-DIP
- Datasheet
- Download
- Description
- FIFO, 64X5, 60NS, ASYNCHRONOUS
- Stock
- 275
- In Stock ：
- 275
Request A Quote(RFQ)
- * Fullname:
- * Company:
- * E-Mail:
- Phone:
- Comment:
- * Quantity:
- Manufacturer :
- Advanced Micro Devices
- Product Category :
- FIFOs Memory
- Organization :
- 64X5
- Qualification Status :
- COMMERCIAL
- Supply Voltage-Max (Vsup) :
- 5.25 V
- RoHS :
- Non-Compliant
- Supplier Device Package :
- 16-PDIP
- Voltage - Supply :
- 4.75 V ~ 5.25 V
- Seated Height-Max :
- 5.08 mm
- Terminal Finish :
- TIN LEAD
- Function :
- ASYNCHRONOUS
- Base Product Number :
- C67402
- Programmable Flags Support :
- No
- Surface Mount :
- No
- Peak Reflow Temperature (Cel) :
- NOT SPECIFIED
- Bus Directional :
- Uni-Directional
- JESD-30 Code :
- R-PDIP-T18
- Package :
- Bulk
- Reach Compliance Code :
- Unknown
- Width :
- 7.62 mm
- Number of Functions :
- 1
- Retransmit Capability :
- No
- Technology :
- TTL
- Access Time :
- 45ns
- Length :
- 22.987 mm
- Operating Mode :
- ASYNCHRONOUS
- Current - Supply (Max) :
- 180mA
- Operating Temperature :
- 0°C ~ 70°C
- Output Enable :
- No
- Package Shape :
- RECTANGULAR
- Terminal Pitch :
- 2.54 mm
- Mounting Type :
- Through Hole
- Manufacturer :
- Rochester Electronics LLC
- FWFT Support :
- No
- Expansion Type :
- Width
- Number of Terminals :
- 18
- Cycle Time :
- 100 ns
- Number of Words :
- 64 words
- Terminal Form :
- THROUGH-HOLE
- Parallel/Serial :
- Parallel
- Pin Count :
- 18
- Terminal Position :
- Dual
- Product Status :
- Active
- Memory Size :
- 64 x 5
- JESD-609 Code :
- e0
- Data Rate :
- 10MHz
- Supply Voltage-Min (Vsup) :
- 4.75 V
- Pbfree Code :
- No
- Memory Width :
- 5
- Memory Density :
- 320 bit
- Series :
- -
- Temperature Grade :
- COMMERCIAL EXTENDED
- Package / Case :
- 16-DIP
- Datasheets
- C67402N
C67402N Documents
FIFOs Memory Advanced Micro Devices C67402N Overview
Introducing the FIFOs Memory Advanced Micro Devices C67402N, a highly reliable and efficient FIFO (First In, First Out) memory component designed for high-speed data buffering applications. This FIFO memory device features a 64x5 organization and offers a rapid access time of 60 nanoseconds. Engineered by Advanced Micro Devices, a leader in semiconductor technology, the C67402N is built for asynchronous operations, enhancing system performance by enabling smoother data flow between mismatched speed processors or varying data buses. Its robust design and fast access time make it an ideal choice for demanding applications that require high-speed data transfer and temporary data storage.
C67402N Features
The C67402N FIFO memory offers several key features that make it an outstanding choice for high-performance computing and communications systems:
- 64x5 Memory Organization: Efficiently manages data with a 64-word by 5-bit structure.
- 60 Nanoseconds Access Time: Ensures quick data retrieval, facilitating high-speed operations.
- Asynchronous Operation: Allows operation with different clock domains, improving versatility in multi-speed environments.
C67402N Applications
- Data Communication: Utilized in high-speed modems and routers to manage data bursts efficiently by temporarily storing incoming data before processing.
- Signal Processing: Plays a critical role in digital signal processors (DSPs) for buffering data during real-time signal analysis, ensuring smooth and uninterrupted signal flow.
- Video Broadcasting: Ideal for use in video broadcast equipment where large amounts of data need to be temporarily stored and synchronized to prevent data loss and ensure seamless transmission.
- Industrial Control Systems: Supports industrial automation by buffering input and output data, facilitating the seamless operation of control logic in real-time systems.
