C4ATJBU4220A3EJ

Manufacturer :

KEMET

Product Category :

Film Capacitors

Voltage Rating - DC :

700V

Length :

32mm

Ratings :

-

Number of Terminals :

2

Lead Diameter :

1.2mm

Depth :

18mm

Dielectric Material :

Polypropylene

Rated (DC) Voltage (URdc) :

700 V

Packaging :

Bulk

Negative Tolerance :

5%

Subcategory :

Capacitors

RMS Current (Irms) :

14A

Product Category :

Film Capacitors

Termination Style :

Radial

Dissipation Factor :

5 x 10⁻⁴ % @1 kHz

Series :

C4AT

Package/Case :

B

Brand :

KEMET

Product Length :

32mm

Positive Tolerance :

5%

RoHS :

Details

Product Width :

18mm

Product Height :

33mm

Features :

-

Number of Pins :

2 Pin

Width :

18 mm

Manufacturer :

KEMET

Type :

Printed Circuit Board Mount Power Film Capacitor

Capacitance :

2.2μF

Terminal Shape :

Wire

REACH SVHC :

No SVHC

Package :

Box

Tolerance :

±5%

Voltage Rating (AC) :

400 V

Termination :

PC Pins

Applications :

DC Link, DC Filtering; High Frequency, Switching

Package Shape :

RECTANGULAR PACKAGE

Ripple Current :

-

Product Type :

Film Capacitors

Mounting Feature :

THROUGH HOLE MOUNT

Lead Pitch :

27.5mm

Lead Spacing :

27.5mm

Qualification :

-

Package / Case :

Radial

Mounting Type :

Through Hole

Max Operating Temperature :

85 °C

Lead Style :

Straight

Reach Compliance Code :

Compliant

ECCN Code :

EAR99

Base Product Number :

C4ATJB

Voltage :

400 V ac, 700 V dc

Height :

33mm

Size / Dimension :

1.260 L x 0.709 W (32.00mm x 18.00mm)

Height - Seated (Max) :

1.299 (33.00mm)

Product :

General Film Capacitors

Minimum Operating Temperature :

-40°C

ESR :

0.004ohm

Maximum Operating Temperature :

+85°C

Product Status :

Active

Operating Temperature :

-40°C ~ 85°C

Voltage Rating - AC :

400V

Capacitor Type :

FILM CAPACITOR

Capacitance Tolerance :

± 5%

Dielectric :

Polypropylene

Voltage Rating (DC) :

400 V

ESR (Equivalent Series Resistance) :

4 MOhms

Min Operating Temperature :

-40 °C

Lead Length :

6mm

Surface Mount :

No

Dimensions :

32 x 18 x 33mm
