BAS316WS

Manufacturer :

Diotec Semiconductor

Product Category :

Diodes - Rectifiers - Single

Terminal Form :

Flat

JESD-30 Code :

R-PDSO-F2

Time@Peak Reflow Temperature-Max (s) :

30

HTS Code :

8541.10.00.70

Terminal Position :

Dual

RoHS Status :

ROHS3 Compliant

Current - Reverse Leakage @ Vr :

1μA @ 75V

Terminal Finish :

Matte Tin (Sn)

Output Current-Max :

0.25A

Surface Mount :

yes

Factory Lead Time :

20 Weeks

Power Dissipation-Max :

0.2W

JESD-609 Code :

e3

Moisture Sensitivity Level (MSL) :

1 (Unlimited)

Package / Case :

SC-90, SOD-323F

Current - Average Rectified (Io) :

250mA

Diode Type :

Standard

Qualification Status :

Not Qualified

Peak Reflow Temperature (Cel) :

260

Configuration :

Single

Packaging :

Digi-Reel®

Operating Temperature - Junction :

-65°C~150°C

Number of Elements :

1

Reverse Recovery Time :

4ns

Operating Temperature (Max) :

150°C

Speed :

Fast Recovery =< 500ns, > 200mA (Io)

Number of Terminations :

2

Voltage - Forward (Vf) (Max) @ If :

1.25V @ 150mA

Diode Element Material :

SILICON

ECCN Code :

EAR99

Voltage - DC Reverse (Vr) (Max) :

100V

Mounting Type :

Surface Mount

Capacitance @ Vr, F :

1.5pF @ 0V 1MHz
