ATTINY24A-CCU

Manufacturer :

Atmel (Microchip Technology)

Product Category :

Microcontrollers

Maximum Operating Temperature :

+ 85 C

JESD-609 Code :

e3

Series :

AVR® ATtiny

Frequency :

20MHz

Additional Feature :

ALSO OPERATES 1.8 V MINIMUM SUPPLY AT 4 MHZ

JESD-30 Code :

S-PBGA-B15

Interfaces :

SPI/USI

Program Memory Size :

2KB 1K x 16

Length :

3mm

Number of I/Os :

12 I/O

PWM Channels :

yes

Speed :

20MHz

Surface Mount :

yes

Supply Voltage-Min (Vsup) :

4.5V

Temperature Grade :

Industrial

Connectivity :

USI

Has ADC :

yes

Product Category :

8-bit Microcontrollers - MCU

Core Size :

8-Bit

Terminal Form :

Ball

Mounting Type :

Surface Mount

ROM Programmability :

Flash

CPU Family :

AVR RISC

Data Bus Width :

8B

Terminal Pitch :

0.65mm

Number of Terminals :

15

Product Type :

8-bit Microcontrollers - MCU

Terminal Finish :

MATTE TIN

Height Seated (Max) :

0.6mm

Power Supplies :

2/5 V

Qualification Status :

Not Qualified

Product :

MCU

Reach Compliance Code :

Compliant

Number of I/O :

12

Product Status :

Active

Package / Case :

15-UFBGA

Tradename :

AVR

ROM (words) :

2048

Core Processor :

AVR

Supplier Device Package :

15-UFBGA (3x3)

Bit Size :

8

Package Shape :

Square

DMA Channels :

No

Moisture Sensitivity Level (MSL) :

3 (168 Hours)

Base Product Number :

ATTINY24

Mounting Style :

SMD/SMT

RoHS :

Details

Packaging :

Tape and Reel (TR)

Supply Voltage :

5V

Operating Temperature :

-40°C~85°C TA

External Data Bus Width :

8

Watchdog Timer :

yes

Seated Height-Max :

0.6 mm

Device Core :

AVR

Number of I/O Lines :

12

Minimum Operating Temperature :

- 40 C

Height :

0.6 mm

Data Converters :

A/D 8x10b

Terminal Position :

BOTTOM

Factory Lead Time :

7 Weeks

Pbfree Code :

yes

Peripherals :

Brown-out Detect/Reset, POR, PWM, Temp Sensor, WDT

Mount :

Surface Mount

Voltage - Supply (Vcc/Vdd) :

1.8V~5.5V

Interface :

SPI

Number of Terminations :

15

Program Memory Type :

Flash

uPs/uCs/Peripheral ICs Type :

MICROCONTROLLER, RISC

Data Converter :

A/D 8x10b

EEPROM Size :

128 x 8

Manufacturer :

Microchip

Interface Type :

SPI, USI

RoHS Status :

ROHS3 Compliant

Number of Timers/Counters :

2

RAM Size :

128 x 8

DAC Channels :

No

Supply Current-Max :

7 mA

Base Part Number :

ATtiny24A

Oscillator Type :

Internal

Published :

1997

Package :

Tape and Reel (TR);Cut Tape (CT);Digi-Reel®;

Width :

3 mm

Memory Size :

2kB

RAM (bytes) :

128

Supply Voltage-Max (Vsup) :

5.5V

Number of Pins :

15

Brand :

Microchip Technology

Contact Plating :

Tin
