AME15-48SJZ-STD

Manufacturer :

Aimtec

Product Category :

Terminal Form :

UNSPECIFIED

Number of Terminals :

8

Number of Outputs :

1

Output Voltage-Max :

48.96 V

Voltage - Isolation :

3 kV

Factory Lead Time :

12 Weeks

Efficiency :

85%

Voltage - Output 3 :

-

Terminal Position :

UNSPECIFIED

Voltage - Output 2 :

48V

Voltage - Output 4 :

-

Color :

Grey

Temperature Grade :

COMMERCIAL

Input Voltage-Nom :

115 V

Approval Agency :

CE, cURus

Material :

PVC

Size / Dimension :

3.78 L x 2.13 W x 1.34 H (96.1mm x 54.0mm x 34.1mm)

Voltage - Output 6 :

-

Product Status :

Active

Trim/Adjustable Output :

No

Package :

Bulk

Voltage - Output 1 :

48V

Current - Output (Max) :

320mA

Applications :

ITE (Commercial)

Total Power Output-Max :

15 W

Number of Functions :

1

Standard Number :

60950-1

Package Shape :

RECTANGULAR

Analog IC - Other Type :

AC-DC REGULATED POWER SUPPLY MODULE

Surface Mount :

No

Power (Watts) :

15W

Manufacturer :

aimtec

Input Type :

AC

Operating Temperature :

-40°C ~ 70°C

Length :

96 mm

Technology :

Hybrid

Features :

-

Base Product Number :

AME15

Series :

AME15-JZ (15W)

Output Voltage-Min :

47.04 V

Pbfree Code :

yes

Reach Compliance Code :

Compliant

Width :

54 mm

Minimum Load Required :

-

Voltage - Output 5 :

-

JESD-30 Code :

R-PXMA-X8
