ADS7816UBG4
Or copy the link below:
- Mfr.Part #
- ADS7816UBG4
- Manufacturer
- Texas Instruments
- Package / Case
- 8-SOIC (0.154, 3.90mm Width)
- Datasheet
- Download
- Description
- IC ADC 12BIT SAR 8SOIC
- Stock
- 30,134
- In Stock ：
- 30,134
Request A Quote(RFQ)
- * Fullname:
- * Company:
- * E-Mail:
- Phone:
- Comment:
- * Quantity:
- Manufacturer :
- Texas Instruments
- Product Category :
- Analog to Digital Converters (ADC)
- Differential Nonlinearity :
- 1 LSB
- Terminal Position :
- Dual
- Packaging :
- Tube
- Number of Analog In Channels :
- 1
- Power Supplies :
- 5V
- Conversion Rate :
- 200 ksps
- Length :
- 4.9mm
- Reference Type :
- External
- Height :
- 1.75mm
- Number of Channels :
- 1
- Pbfree Code :
- yes
- Peak Reflow Temperature (Cel) :
- 260
- Architecture :
- SAR
- Radiation Hardening :
- No
- Operating Temperature :
- -40°C~85°C
- Base Part Number :
- ADS7816
- Ratio - S/H:ADC :
- 1:1
- Terminal Form :
- Gull wing
- Sampling Rate (Per Second) :
- 200k
- Lead Free :
- Lead Free
- Number of Pins :
- 8
- Number of Bits :
- 12
- REACH SVHC :
- No SVHC
- Min Supply Voltage (DC) :
- 4.75V
- Pin Count :
- 8
- Number of Functions :
- 1
- ECCN Code :
- EAR99
- Package / Case :
- 8-SOIC (0.154, 3.90mm Width)
- Max Supply Voltage (DC) :
- 5.25V
- Polarity :
- Unipolar
- Width :
- 3.91mm
- Surface Mount :
- yes
- Integral Nonlinearity (INL) :
- 2 LSB
- Supply Type :
- Single
- Interface :
- Serial
- Nominal Supply Current :
- 380μA
- JESD-609 Code :
- e4
- Converter Type :
- ADC, SUCCESSIVE APPROXIMATION
- Sample and Hold / Track and Hold :
- SAMPLE
- Contact Plating :
- Gold
- Thickness :
- 1.58mm
- Input Type :
- Differential
- RoHS Status :
- Non-RoHS Compliant
- Power Consumption :
- 1.9mW
- Power Dissipation :
- 1.9mW
- Max Power Dissipation :
- 1.9mW
- Max Supply Voltage :
- 5.25V
- Factory Lead Time :
- 6 Weeks
- Mounting Type :
- Surface Mount
- Output Bit Code :
- BINARY
- Lifecycle Status :
- ACTIVE (Last Updated: 5 days ago)
- Configuration :
- S/H-ADC
- Sampling Rate :
- 200 ksps
- Number of Terminations :
- 8
- Operating Supply Voltage :
- 5V
- Moisture Sensitivity Level (MSL) :
- 2 (1 Year)
- Data Interface :
- SPI
- Spurious-free dynamic range (SFDR) :
- 86 dB
- Resolution :
- 1.5 B
- Supply Voltage :
- 5V
- Voltage - Supply, Analog :
- 5V
- Analog Input Voltage-Max :
- 5V
- Min Supply Voltage :
- 4.5V
- Datasheets
- ADS7816UBG4
Analog to Digital Converters (ADC) Texas Instruments ADS7816UBG4 Overview
The ADS7816UBG4 from Texas Instruments represents a pinnacle in compact, high-efficiency Analog to Digital Converters (ADCs). Designed specifically for applications requiring precise data acquisition, this 12-bit, successive approximation register (SAR) ADC offers fast sampling rates and low power consumption in a small 8SOIC package. Its robust design and industry-leading performance make it ideal for a range of demanding applications, ensuring that every quantization delivers not only precision but also repeatability, crucial for industrial and commercial settings. Emphasizing the high caliber of [Analog to Digital Converters (ADC) Texas Instruments ADS7816UBG4], this product stands out for its ability to integrate seamlessly into existing technology stacks, enhancing system reliability and functionality.
ADS7816UBG4 Features
This ADC unit features a 12-bit resolution with a compact 8SOIC package that ensures a minimal footprint on any PCB layout. Its low power consumption, requiring only a single power supply ranging from 2.7V to 5.5V, is particularly beneficial for portable and remote sensing applications. Additionally, the ADS7816UBG4 boasts a high-speed SPI-compatible serial interface, making it easy to integrate with most microcontrollers and digital systems, enhancing both scalability and ease of use.
ADS7816UBG4 Applications
- Medical Devices: Utilized in patient monitoring systems to convert analog signals from medical sensors into digital data for accurate monitoring and analysis.
- Portable Instrumentation: Empowers field devices with its low power consumption and high accuracy, making it suitable for environmental monitoring or on-the-go diagnostic tools.
- Industrial Automation: Facilitates precise control in automated processes by converting sensor outputs to digital data, optimizing operations in manufacturing and processing industries.
- Data Acquisition Systems: Critical in gathering precise and rapid data for research and development across scientific disciplines, ensuring data integrity and reliability.
