ADG5401FBCPZ-RL7

Manufacturer :

Analog Devices, Inc.

Product Category :

Analog Switches, Multiplexers, Demultiplexers

Product Status :

Active

Dual Supply Voltage (Min) :

±5(V)

Chip Enable Signals :

yes

Number of Inputs :

1

Voltage - Supply, Dual (V±) :

±5V ~ 22V

Power Supply Requirement :

Single/Dual

Base Product Number :

ADG5401

Dual Supply Voltage (Typ) :

±15/±20(V)

RoHS :

Details

Supplier Device Package :

10-LFCSP (3x2)

Single Supply Voltage (Min) :

8(V)

Dual Supply Voltage (Max) :

±22(V)

Single Supply Voltage (Max) :

44(V)

Mounting Type :

Surface Mount

Series :

-

Supply Type :

Single Supply, Dual Supply

Configuration :

4 x SPST

Product Category :

Analog Switch ICs

Pin Count :

10

Minimum Operating Temperature :

- 40 C

Product Type :

Analog Switch ICs

Current - Leakage (IS(off)) (Max) :

100pA (Typ)

Charge Injection :

-230pC

Package :

Tape and Reel (TR);Cut Tape (CT);Digi-Reel®;

-3db Bandwidth :

395MHz

Voltage - Supply, Single (V+) :

8V ~ 44V

Single Supply Voltage (Typ) :

12/36(V)

Number of Channels :

1

Switch Time (Ton, Toff) (Max) :

10.2µs, 360ns

Output Signal Type :

Single

Maximum Operating Supply Voltage :

44 V

Maximum Operating Temperature :

+ 125 C

Number of Outputs :

1

Brand :

Analog Devices

Mounting :

Surface Mount

Rad Hardened :

No

Input Signal Type :

Single

Multiplexer/Demultiplexer Circuit :

1:1

Subcategory :

Switch ICs

Crosstalk :

-

Operating Temperature :

-40°C ~ 125°C

Packaging :

Tape and Reel

On-State Resistance (Max) :

6Ohm (Typ)

Type :

Analog Switch

Channel Capacitance (CS(off), CD(off)) :

9pF, 11pF

Switch Circuit :

SPST - NC

Manufacturer :

Analog Devices Inc.

Operating Temp Range :

-40C to 125C

Number of Circuits :

1

Operating Temperature Classification :

Automotive

Package / Case :

LFCSP-10

Package Type :

LFCSP

Mounting Style :

SMD/SMT
