ADF7011BRUZ-RL7

Manufacturer :

Analog Devices, Inc.

Product Category :

RF Transmitters

Modulation or Protocol :

ASK, FSK, GFSK, OOK

Width :

4.4mm

Current - Transmitting :

34mA

Number of Terminations :

24

Terminal Pitch :

0.65mm

Voltage - Supply :

2.3V~3.6V

Data Rate (Max) :

76.8kbps

Applications :

Data Transfer, RKE, Remote Control/Security Systems

Package / Case :

24-TSSOP (0.173, 4.40mm Width)

Terminal Finish :

MATTE TIN

Time@Peak Reflow Temperature-Max (s) :

40

Packaging :

Tape and Reel (TR)

Number of Functions :

1

Peak Reflow Temperature (Cel) :

260

Antenna Connector :

PCB, Surface Mount

Qualification Status :

COMMERCIAL

Terminal Form :

Gull wing

JESD-609 Code :

e3

Frequency :

433MHz~435MHz; 866MHz~870MHz

Supply Voltage :

3V

Terminal Position :

Dual

Surface Mount :

yes

Operating Temperature :

-40°C~85°C

Length :

7.8mm

Telecom IC Type :

TELECOM CIRCUIT

RoHS Status :

ROHS3 Compliant

JESD-30 Code :

R-PDSO-G24

Moisture Sensitivity Level (MSL) :

1 (Unlimited)

Height Seated (Max) :

1.2mm

Power - Output :

-16dBm~12dBm

Pin Count :

24

Pbfree Code :

yes

Data Interface :

PCB, Surface Mount
