AD9700SE
- Mfr.Part #
- AD9700SE
- Manufacturer
- Analog Devices, Inc.
- Package / Case
- 20-CLCC
- Datasheet
- Download
- Description
- DAC, PARALLEL, 8 BITS INPUT
- Stock
- 30,686
- In Stock :
- 30,686
Request A Quote(RFQ)
- * Fullname:
- * Company:
- * E-Mail:
- Phone:
- Comment:
- * Quantity:
- Manufacturer :
- Analog Devices, Inc.
- Product Category :
- Digital to Analog Converters (DAC)
- ECCN Code :
- EAR99
- Reach Compliance Code :
- Unknown
- Temperature Grade :
- Military
- Settling Time :
- 12ns
- Qualification Status :
- Not Qualified
- Series :
- AD9700
- HTS Code :
- 8542.39.00.01
- Converter Type :
- D/A CONVERTER
- Reference Type :
- Internal
- Terminal Pitch :
- 1.27 mm
- Supplier Device Package :
- 20-CLCC (9x9)
- Architecture :
- R-2R
- Differential Output :
- No
- Manufacturer :
- Rochester Electronics LLC
- Input Bit Code :
- COMPLEMENTARY BINARY
- Seated Height-Max :
- 2.54 mm
- Pin Count :
- 28
- Width :
- 11.43 mm
- JESD-30 Code :
- S-CQCC-N28
- Negative Supply Voltage-Nom :
- -5.2 V
- Length :
- 11.43 mm
- Number of Functions :
- 1
- Terminal Form :
- NO LEAD
- Linearity Error-Max (EL) :
- 0.2%
- Operating Temperature :
- -25°C ~ 85°C
- Package / Case :
- 20-CLCC
- Voltage - Supply, Analog :
- 5V ~ 5.5V
- Data Interface :
- -
- Terminal Finish :
- TIN LEAD
- Surface Mount :
- yes
- Mounting Type :
- Surface Mount
- Output Type :
- Voltage or Current - Unbuffered
- Voltage - Supply, Digital :
- 5V ~ 5.5V
- Product Status :
- Active
- Number of D/A Converters :
- 1
- Pbfree Code :
- No
- Package :
- Bulk
- Analog Output Voltage-Min :
- -0.6375 V
- Number of Terminals :
- 28
- Peak Reflow Temperature (Cel) :
- NOT SPECIFIED
- Terminal Position :
- QUAD
- Input Format :
- PARALLEL, 8 BITS
- Package Shape :
- Square
- JESD-609 Code :
- e0
- Number of Bits :
- 8
- INL/DNL (LSB) :
- ±0.2FSR, ±0.2FSR
