9310-40-RC

Manufacturer :

Bourns, Inc.

Product Category :

Fixed Inductors

JESD-609 Code :

e3

Package / Case :

Axial

Military Standard :

Not

Number of Terminations :

2

RoHS Status :

ROHS3 Compliant

Material - Core :

Ferrite

Series :

9310

Shape/Size Description :

TUBULAR PACKAGE

Quality Factor-Min (at L-nom) :

65

ECCN Code :

EAR99

DC Current :

370mA

Number of Pins :

2

Tolerance :

±10%

Contact Plating :

Tin

Test Frequency :

2.5MHz

Published :

2012

Construction :

Molded

Operating Temperature :

-55°C~105°C

Number of Functions :

1

Inductance Tolerance :

10%

Current Rating :

370mA

Type :

Wirewound

Frequency - Self Resonant :

40MHz

REACH SVHC :

No SVHC

Q Factor :

65

Moisture Sensitivity Level (MSL) :

1 (Unlimited)

Size / Dimension :

0.156Diax0.375L 3.96mmx9.53mm

Max DC Current :

370mA

DC Resistance (DCR) :

1.4Ohm Max

HTS Code :

8504.50.40.00

Lead Diameter :

640 μm

Inductor Application :

RF INDUCTOR

Q @ Freq :

65 @ 2.5MHz

Inductance :

15μH

Diameter :

3.96mm

Packaging :

Bulk

Shielding :

No

Mounting Type :

Through Hole

Mount :

Through Hole
