76-HIMD22L

Manufacturer :

NTE Electronics, Inc.

Product Category :

Quick Connects, Quick Disconnect Connectors

Material Flammability Rating :

-

Product Status :

Active

Orientation :

C

Insulated :

Insulated

Package :

Bag

Wire Size (AWG) :

22 AWG, 21 AWG, 20 AWG, 19 AWG, 18 AWG

Gender :

Male

Insulation Diameter :

-

Shell Size, MIL :

H

Mounting Type :

Free Hanging (In-Line)

Length - Overall :

1.457 (37.00mm)

Applications :

Aviation, Marine, Military

Insulation :

Non-Mating End Heat Shrink

Terminal Type :

Disconnect - Male

Ingress Protection :

IP67 - Dust Tight, Waterproof

Contact Finish Thickness - Mating :

50.0µin (1.27µm)

Color :

-

Manufacturer :

NTE Electronics

Contact Material :

COPPER ALLOY

Package Quantity :

50

Shell Material :

Stainless Steel

Shell Finish :

Passivated

Voltage Rating :

-

Contact Finish :

Electro-Tin

Insert Material :

Thermoplastic

Features :

Coupling Nut

Current Rating (Amps) :

5A

Insulation Material :

Heat Shrinkable Tube

Shielding :

Shielded

Shell Size - Insert :

23-35

Fastening Type :

Threaded

Number of Positions :

100

Wire Size :

22-18 AWG

Wire Gauge :

18-22 AWG

Tab Thickness :

0.032 (0.81mm)

Tab Width :

0.250 (6.35mm)

Base Product Number :

D38999/26KH

Operating Temperature :

-65°C ~ 200°C

Terminal Material :

Brass

Tab Size :

0.25 x 0.032

Contact Finish - Mating :

Gold

Material :

Tin Plated Brass

Connector Type :

Plug, Male Pins

Cable Opening :

-

Termination :

Crimp

Mounting Feature :

-

Backshell Material, Plating :

-

Series :

Military, MIL-DTL-38999 Series III

Primary Material :

Metal
