74HC299D,653

Manufacturer :

Nexperia

Product Category :

Universal Bus Functions

Number of Circuits :

8-Bit

Propagation Delay (tpd) :

60 ns

Package / Case :

20-SOIC (0.295, 7.50mm Width)

Width :

7.5mm

JESD-609 Code :

e4

Time@Peak Reflow Temperature-Max (s) :

30

Peak Reflow Temperature (Cel) :

260

Published :

1995

RoHS Status :

ROHS3 Compliant

Moisture Sensitivity Level (MSL) :

1 (Unlimited)

Qualification Status :

Not Qualified

Number of Functions :

1

Series :

74HC

fmax-Min :

17 MHz

Pin Count :

20

Mounting Type :

Surface Mount

Height Seated (Max) :

2.65mm

Supply Voltage-Min (Vsup) :

2V

Supply Voltage :

5V

Supply Voltage-Max (Vsup) :

6V

Terminal Position :

Dual

Count Direction :

Bidirectional

Trigger Type :

POSITIVE EDGE

Terminal Pitch :

1.27mm

Voltage - Supply :

2V~6V

Surface Mount :

yes

Additional Feature :

HOLD MODE; COMMON I/O PINS; TOTEMPOLE SERIAL SHIFT RIGHT and SHIFT LEFT OUTPUTS; GATED OUTPUT CONTROL

Load Capacitance :

50pF

Family :

HC/UH

Current - Output High, Low :

6mA 6mA

Packaging :

Tape and Reel (TR)

Number of Pins :

20

Output Characteristics :

3-STATE

Output Polarity :

TRUE

Base Part Number :

74HC299

HTS Code :

8542.39.00.01

Operating Temperature :

-40°C~125°C

Terminal Finish :

Nickel/Palladium/Gold (Ni/Pd/Au)

Length :

12.8mm

Number of Bits :

8

Number of Terminations :

20

Terminal Form :

Gull wing

Factory Lead Time :

4 Weeks

Logic Type :

Universal Shift Register
